Type:
Bullet
Features:
AI
Frame Rate:
High
Sensor Type:
1/1.7" Progressive Scan CMOS
Max. Resolution:
4000 × 3000
Min. Illumination:
0.009 Lux color / 0.0009 Lux B/W
Shutter Time:
1 s to 1/100,000 s
Day & Night:
IR cut filter
Focus:
Auto, semi-auto, manual
Focal Length & FOV:
2.8-12mm (96.2°-36.4°H) / 8-32mm (40.2°-14.4°H)
Aperture:
2.8 to 12 mm: F1.2 to F2.5;8 to 32 mm: F1.7 to F1.73
Lens Mount:
Integrated
Supplement Light Range:
2.8 to 12 mm: 50 m;8 to 32 mm: 100 m
IR Wavelength:
850 nm
Smart Supplement Light:
Yes
Main Stream:
4096×2160 @ 25fps
Sub-Stream:
704×576 @ 25fps
Third Stream:
1920×1080 @ 25fps
Fourth Stream:
30 fps (1920×1080)
Fifth Stream:
25-30 fps (704×576 to 640×480)
Custom Stream:
25-30 fps (1920×1080, 1280×720, 704×576, 640×480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Target Cropping:
Yes
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate:
8–320 Kbps
Audio Type:
Mono sound
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Smooth Streaming:
Yes
User/Host:
32 users, 3 levels
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP OVER HTT
Network Storage:
NAS (NFS, SMB/CIFS), auto network replenishment (ANR);Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+, +more
Wide Dynamic Range (WDR:
Digital WDR
Day/Night Switch:
Day, Night, Auto, Schedule, Alarm Trigger
Picture Overlay:
Logo overlay, 128×128 24-bit BMP
Image Enhancement:
BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction
Image Parameters Switch:
Yes
Image Settings:
Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
SNR:
≥52 dB
Alarm:
2 input, 2 outputs (max. 24 VDC, 1 A)
Audio Support:
-IZHY: 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-e
RS-485:
1x RS-485 half duplex
Video Outputs:
1 Vp-p Composite Output (75Ω/CVBS) (For debugging only)
On-Board Storage:
microSD up to 256 GB
Reset Key:
Yes
Ethernet Interface:
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Power Output:
12 VDC, 100 mA
Basic Event:
Motion detection, video tampering alarm, vibration detection, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Linkage:
Recording & alert: FTP/NAS, email, alarm, capture
Smart Event:
Line crossing detection, up to 4 lines configurable;Intrusion detection, up to 4 regions configurable;Region entrance detection, up to 4 regions configurable;Region exiting detection, up to 4 regions configurable;Unattended baggage detection, up to 4
Face Capture:
30 faces, ±60° pan, ±30° tilt
Multi-Target-Type Detection:
Human & face detection, 8 face + 13 body features
People Counting:
Yes
Queue Management:
Queue detection & wait time tracking
Perimeter Protection:
Line crossing, intrusion, region alerts
Power Type:
PoE
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
Heater:
Yes
General Function:
Anti- flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Storage Conditions:
-40 to 60°C, 95% RH non-condensing
Startup And Operating Conditions:
-40°C to 60°C
Material:
Aluminum alloy body
Dimension:
Ø144 × 347 mm / Ø140 × 351 mm
Package Dimension:
405 mm × 190 mm × 180 mm (15.9" × 7.5" × 7.1")
Weight:
Approx. 1920 g (4.2 lb.)
With Package Weight:
Approx. 3060 g (6.7 lb.)
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Environment Rating:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
Automotive And Railway:
With -R: EN50121-4
Anti-Corrosion Protection:
With -Y: NEMA 4X (NEMA 250-2018)
Other:
With -Y: PVC FREE
Product Type:
Bullet
Connectivity:
Wired
IP Rating:
IK10
Night Vision:
IR
PoE Class:
2
Form Factor:
Bullet
Vandal Rating:
IK10
Compatibility:
ONVIF
Max Channels:
20
Resolution:
12MP
Day/Night:
Yes
Analytics:
People Counting
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Lens Type:
Varifocal
Image Sensor Size:
1/1.7"
Horizontal Fov:
96.2°
Vertical Fov:
69.3°
Image Stabilization:
Yes
Wide Dynamic Range:
WDR
Housing Color:
White
Warranty:
5-year warranty
Package Contents:
1 × Hikvision 12MP AI Bullet Network IP Camera IDS-2CD7AC5G0-IZHSY; 1 × Mounting Bracket; 1 × Set of Mounting Screws; 1 × Quick Start Guide; 1 × Waterproof Connector
