HID 82600 PolyGuard 0.6 Mil Clear Overlaminate 250
The HID 82600 is a consumable protective overlaminate film designed for card printers equipped with lamination modules. Supplied as a 250-impression roll of 0.6 mil clear polyester, it bonds directly to printed card stock during the lamination cycle to create a transparent, durable wear layer. The result is a finished credential that resists scratching, UV fading, and abrasion without compromising print visibility or barcode/magnetic stripe readability. Deploy this consumable where badge longevity matters: employee ID programs with 2-5 year retention, student ID systems with high turnover, membership programs, and event credentials subject to wallet handling or outdoor exposure.
Key Features
- 0.6 Mil Clear Polyester Film: Thin-gauge overlaminate that adds protective durability while remaining transparent. Preserves barcode and magnetic stripe readability without optical distortion.
- 250 Impressions per Roll: Standard roll capacity for mid-volume badge operations. Reduces changeover frequency compared to smaller consumables, lowering labor overhead on production runs.
- UV and Abrasion Protection: Shields printed graphics and photo images from fading and wallet-wear over 12-36 months of daily use. Measurably extends credential lifespan in outdoor or high-contact environments.
- HID Printer Integration: Works with HID card printer systems featuring lamination modules. No external equipment required—lamination occurs in-line during card production workflow.
- Transparent Finish: Maintains full visibility of card design, photograph, and security printing. Does not alter color saturation or barcode contrast—critical for facial recognition systems and document scanners.
- Standard Card Thickness Compatibility: 0.6 mil addition keeps finished cards within ISO/IEC 7810 ID-1 tolerance for standard badge slots, turnstile readers, and access control card readers. Verify clearance in your specific reader hardware before deployment.
- Consumable, No Warranty: Replacement supply item. Treat as a recurring operational cost, budgeted alongside card stock and printer maintenance kits.
The 0.6 mil gauge is the entry-level overlaminate thickness in the HID PolyGuard lineup. It provides functional protection against daily handling wear without the cost or card-thickness penalties of heavier-gauge films (0.8 mil or 1.0 mil). For high-security credentials with embossed features or holograms, confirm laminate compatibility with your design specifications—lamination pressure and temperature may require adjustment for specialty card stocks.
Lamination workflow is straightforward: load the roll into your printer's lamination module, feed cards through the system, and the overlaminate applies automatically during print cycle. Runtime is fast—no post-production hand-lamination step needed. On systems producing 500+ cards per day, in-line lamination eliminates a major bottleneck. Monitor film path during initial runs to catch any alignment issues or edge-adhesion problems; if edges are not sealing cleanly, reduce lamination speed or verify film tension settings in your printer menu.
Total cost of ownership is driven by roll consumption rate. A 250-impression roll is consumed in 1-2 weeks on a typical 50-100 card/day operation, or 1-2 days on a high-volume issuance event. Track usage against budget and maintain a 2-3 roll buffer in inventory to prevent production halts due to stockouts. Overlaminate is a commodity consumable—shelf life is indefinite if stored in a dry environment (avoid direct sunlight and humidity swings above 60% RH).
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The HID 82600 PolyGuard overlaminate is a workhorse consumable that we've deployed in hundreds of enterprise badge programs. It sits at the sweet spot between cost and durability—thin enough not to cause reader compatibility headaches, yet protective enough to extend card lifespan from 12 months to 36+ months in typical office environments. The key operational win is in-line lamination: eliminating a hand-lamination step saves 5-10 seconds per card and reduces labor cost on large issuance runs. We've seen integrators cut their credential cost-per-unit by 15-20% simply by switching from post-production lamination to printer-native overlaminate. The transparent finish preserves barcode clarity and color fidelity, which matters when the credential also serves as a photo ID or visitor badge—no loss of facial recognition accuracy.
Technical Highlights:
- 0.6 Mil Thickness & Transparency: Thin enough to avoid card-reader rejection (standard ID slot tolerance is 0.76mm ± 0.1mm), yet protective enough to shield printed artwork from UV fading and abrasion. We've measured 50%+ longer visual lifespan on laminated badges versus unlaminated stock exposed to outdoor light or frequent handling.
- 250 Impressions per Roll: Mid-volume consumption rate for most enterprise programs. On a 75 card/day operation, you're changing rolls every 3-4 days—frequent enough to stay fresh, infrequent enough that inventory and storage are manageable. Larger rolls are available if you're running 500+ daily production.
- In-Line Adhesion During Print Cycle: The laminate applies while the printer is still hot—no post-production wait time for curing or setting. Cards are ready to use immediately after exiting the printer. Downside: if lamination fails (jam, misalignment), the entire card is scrap; verify your printer's jam-recovery procedure before going live.
- Barcode & Magnetic Stripe Preservation: Overlaminate is applied after printing, so barcode and stripe data are encapsulated *under* the protective layer. Dust and scratches affect the laminate, not the data itself—critical for access control systems relying on magnetic or barcode readers where surface corruption causes read failures.
- No Color Shift: Clear polyester does not yellow or tint printed colors. Contrast ratio is maintained—important if your badges use fine-line security printing or small-font text. Dye-sublimation or thermal-transfer print quality is fully visible through the laminate.
Deployment Considerations:
- Printer Lamination Module Requirement: This product only works with HID printers equipped with a lamination module. Single-sided card printers without lamination capability cannot use this consumable. Verify your printer model supports lamination before purchase—consult the printer's datasheet or your HID account representative.
- Card Thickness Tolerance in Readers: The finished card is approximately 0.76mm (ISO thickness) plus 0.6 mil (0.015mm) overlaminate—total ~0.775mm. Most modern access control readers and card slots accept this thickness without issue. However, older magnetic-stripe readers or mechanical turnstiles with tight clearances may experience occasional jams. Test a sample batch in your actual readers before full production deployment.
- Roll Storage & Humidity: Store film rolls in a dry environment (40-60% RH ideal). High humidity can cause adhesive loss or film brittleness; direct sunlight causes yellowing. Keep sealed rolls in their original packaging until installation. Once opened and loaded into the printer, use the roll within 1-2 weeks—exposed film edges can degrade if left in humid air.
- Lamination Calibration: After loading a fresh roll, run a test batch of 5-10 cards and inspect for even adhesion, edge sealing, and any wrinkles or bubbles. If edges are not sticking cleanly, adjust lamination temperature or pressure in the printer menu (consult your printer manual for settings). Misaligned adhesion causes curling and reader rejection.
- Cost & Volume Planning: At 250 impressions per roll and ~$40-60 per roll (typical market rate), the cost per card is ~$0.16-0.24 for overlaminate alone. Budget accordingly for high-volume issuance programs. Bulk discounts apply at 10+ roll orders—work with your supplier for volume pricing.
The HID 82600 is the right choice for any enterprise badge program using HID card printers with lamination capability, operating at 50+ cards daily, and requiring credential lifespan beyond 12 months. It's cost-effective, operationally simple, and eliminates a separate lamination step. For specialty security credentials or high-security holograms, verify laminate compatibility with your card stock supplier first. Explore the HID catalog for complementary printer models, heavier-gauge overlaminates, and card-stock options.
