Type:
Dome
Frame Rate:
30fps
Imaging Device:
1/1.8" progressive CMOS
Resolution:
3840×2160
Max. Framerate:
30fps @ 8MP
Min. Illumination:
0.04 Lux color / 0 Lux IR
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation; USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio:
4.4~9.3mm(2.1x) motorized varifocal
Max. Aperture Ratio:
F1.3(Wide)~F2.15(Tele)
Angular Field of View:
H: 113°, V: 58°
Min. Object Distance:
0.5m(1.64ft)
Focus Control:
Simple focus, Manual
Lens Type:
P-iris(IR corrected)
Pan / Tilt / Rotate Range:
0°~360° / -45°~85° / 0°~355°
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
extremeWDR(120dB)
Digital Noise Reduction:
WiseNRⅡ(Based on AI engine), SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point Polygonal zones
Privacy Masking:
32ea, 4point Quadrangle zones; - Color: Gray/Green/Red/Blue/Black/White; - Mosaic
Gain Control:
Off / Max Gain / Manual
White Balance:
ATW / NarrowATW / AWC / Manual / Indoor / Outdoor
LDC:
Support(Fill/stretch mode)
Electronic Shutter Speed:
2-1/12,000 sec
Video Rotation:
Flip, Mirror, Hallway view(90°/270°)
Analytics:
Classified object type: Person/Face/Vehicle/License plate; Attributes: Vehicle(Type: car/bus/truck/motorcycle/bicycle); Support DetectionShot; Analytics events based on AI engine; - Object detection, Virtual line(Crossing/Direction), Virtual area(Loi
Business Intelligence:
People counting, queue management, heatmap
Alarm Inputs/Outputs:
2 configurable I/O ports, DC 12V output(Max. 50mA)
Alarm Triggers:
Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription
Alarm Events:
When alarm trigger occurred; - File upload(image): e-mail/FTP; - Notification: e-mail; - Recording: SD/SDHC/SDXC or NAS recording at event triggers; - Alarm output; - Handover: PTZ preset, send message by HTTP/HTTPS/TCP; - Audio clip playback; - MQTT
Audio In:
Selectable(mic in/line in/built-in MIC); Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max.output level: 1Vrms
IR Viewable Length:
WiseIR 50m(164.04ft)
Ethernet:
Metal shielded RJ-45(10/100/1000BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable, G.726(ADPCM) 8KHz, +more
Smart Codec:
WiseStream II, WiseStream III
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles, 3 virtual channel support)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT
Security:
TPM 2.0(FIPS 140-2 level 2); HTTPS(SSL) Login Authentication; Digest Login Authentication; IP Address Filtering; User access log; 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2); Device Certificate(Hanwha Techwin Root CA, pre-installed);
Application Programming Interface:
ONVIF Profile S/G/T/M; SUNAPI; Wisenet
Webpage Language:
English, Korean, Chinese, French, Italian, +more
Edge Storage:
Micro SD/SDHC/SDXC 2slot Max. 1TB(512GB * 2)
RAM:
4GB RAM, 512MB Flash
Operating Temperature / Humidity:
-25°C to 50°C / 0-95% RH non-condensing
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / 0~90% RH
Certification:
IP52, IK10
Input Voltage:
PoE+(IEEE802.3at type2, Class4), 12VDC
Power (Max:
22.5W
Color / Material:
White / Aluminum; Hard-coated dome bubble
RAL Code:
RAL9003
Product Dimensions / Weight:
ø160x125mm(ø6.30x4.92"), 1600g(3.53 lb)
Compatible Conduit hole / Gangbox:
12.7mm(1/2")(M20); single, double, 4" octagon, 4" square
Hanging Mount (Dome:
SBP-167HMW
EMC:
FCC 47 CFR 15 Subpart B Class A; ICES-3(A)/NMB-3(A); CE/UKCA; - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3; VCCI CISPR 32 Class A; RCM AS/NZS CISPR 32 Class A; KS C 9832 Class A, KS C 9835
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1; IEC/EN 62471
Environment Rating:
IEC/EN 63000; IEC/EN 60529 IP52, IEC/EN 62262 IK10
Detect (25PPM/ 8PPF:
Wide: 50.8m(166.77ft) / Tele: 176.6m(579.49ft)
Observe (63PPM/ 19PPF:
Wide: 20.3m(66.71ft) / Tele: 70.7m(231.80ft)
Recognize (125PPM/ 38PPF:
Wide: 10.2m(33.35ft) / Tele: 35.3m(115.90ft)
Identify (250PPM/ 76PPF:
Wide: 5.1m(16.68ft) / Tele: 17.7m(57.95ft)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP52
Features:
WDR
Night Vision:
IR
Power Type:
PoE+
PoE Class:
4
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
0.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
HTTPS Encryption:
Yes
WDR:
WDR
Housing Color:
White
Warranty:
3-year warranty
Poe Power:
PoE+ (802.3at)
Ir Lowlight:
IR
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
Varifocal
Compatible Accessories:
(Optional)
Lens:
Type P-iris(IR corrected)
Camera:
Title Displayed up to 85 characters
Ethernet Rate:
Metal shielded RJ-45(10/100/1000BASE-T)
Application:
Programming Interface ONVIF Profile S/G/T
Memory:
4GB RAM, 512MB Flash
Operating Temp:
/ Humidity -25 °C ~ 50 °C(-13°F ~ +122°F)
Storage:
Temperature / Humidity -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
