Hanwha TNV-C8014RM 5MP Mobile AI IR Vandal Dome Network Camera

The Hanwha TNV-C8014RM is a 5-megapixel mobile AI-powered IR vandal dome camera purpose-built for high-security surveillance in transportation, fleet, and mobile environments. This ruggedized network camera combines advanced AI analytics, robust vandal protection, and all-weather performance to deliver reliable monitoring in the most demanding conditions.

Key Features

• 5MP resolution at 30fps with 3.0mm fixed lens (100° H / 73° V FOV)
• AI-based object classification (person/vehicle detection)
• Intelligent Video Analytics: virtual line crossing, area intrusion detection, defocus detection, shock detection
• IR illumination up to 30 meters for 24/7 visibility
• 120dB Wide Dynamic Range for challenging lighting conditions
• Triple codec support: H.265, H.264, MJPEG with WiseStream III optimization
• IP66 and IK10 ratings for water, dust, and vandal resistance
• Built-in microphone with audio support
• Internal SD card storage up to 256GB
• Operating temperature: -40°C to +55°C

Technical Highlights

The TNV-C8014RM delivers superior image quality through its 120dB WDR capability, enabling clear video capture in high-contrast environments where lighting varies dramatically. The 30-meter IR range ensures effective night vision without relying on external lighting infrastructure. Advanced noise reduction (WiseNR II) and Digital Image Stabilization with integrated gyro sensor maintain clarity even in mobile or vibration-prone installations.

Codec flexibility is a standout feature. H.265 compression reduces bandwidth consumption by up to 50% compared to H.264, critical for mobile and remote deployments with limited network resources. WiseStream III technology intelligently adapts compression based on scene complexity, optimizing storage and transmission efficiency without sacrificing image quality.

The AI engine provides real-time object classification and advanced analytics without requiring external processing servers. Virtual line crossing, area intrusion detection, defocus detection, and shock detection enable intelligent event-driven recording and alerting. Hallway view mode supports vertical monitoring for vehicles and corridors, while dynamic privacy masking protects sensitive areas.

Durability & Environmental Performance

IP66 certification guarantees protection against high-pressure water jets and dust ingress, essential for outdoor mobile and transportation environments. The IK10 vandal rating withstands impacts up to 20 joules, protecting the camera from deliberate tampering or accidental collision damage. A built-in heater ensures operation across extreme temperature ranges from -40°C to +55°C, supporting deployment in arctic and desert climates.

Applications

• Fleet and vehicle surveillance
• Public transportation (buses, trains, trams)
• Mobile command centers and temporary installations
• Perimeter security in harsh outdoor environments
• Critical infrastructure monitoring
• Parking facilities and access points

James Everett

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The TNV-C8014RM excels in mobile surveillance scenarios where traditional fixed installations are impractical. Its combination of AI analytics, robust protection ratings, and efficient compression makes it ideal for fleet operators and transportation authorities requiring reliable, scalable monitoring. The integrated storage capability reduces dependency on network connectivity, critical for mobile deployments with intermittent links.

The shock and defocus detection features add operational intelligence, alerting operators to camera tampering or obstruction in real-time. For organizations balancing cost, performance, and durability in demanding mobile environments, this camera delivers exceptional value.

Available in White.
