Vertiv GXT5 Output POD 1 - PD5-001

Vertiv PD5-001 GXT5 Output POD Power Distribution Unit

Overview

The Vertiv PD5-001 is a rack-mounted output power distribution unit (POD) designed exclusively for the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN UPS systems. Where those 5kVA and 6kVA units deliver raw 30A power on a single NEMA L14-30P output, the PD5-001 (often searched as PD5 001) fans that single connection into six discrete receptacles — four NEMA 5-15/20R duplex outlets, one NEMA L14-30R locking outlet, and one NEMA L6-30R locking outlet — giving you the mixed receptacle mix that real server-room and edge-compute deployments actually need without adding a separate PDU between the UPS and your equipment rack.

Explore the broader Vertiv power and infrastructure lineup if you need to evaluate the full GXT5 family or complementary distribution accessories.

Key Features

• NEMA L14-30P Input at 30A Maximum: The L14-30P locking plug connects directly to the matching output on the GXT5-5000MVRT4UXLN or GXT5-6000MVRT4UXLN UPS — no adapters, no loose connections. The 30A maximum current rating means you can fully load the UPS output without the POD becoming the bottleneck. Plan your receptacle load budget so no single branch circuit exceeds its rated ampacity.
• (4) NEMA 5-15/20R Duplex Receptacles: Four dual-rated 15/20A outlets handle the majority of server, networking, and storage loads in a standard rack — 1U switches, 1U servers, KVM units, and similar gear all plug in without locking connectors. Spreading load across four receptacles also makes circuit-level monitoring and management easier if you add a monitoring-capable PDU downstream.
• (1) NEMA L14-30R Locking Outlet: The single L14-30R receptacle is the right connection point for a downstream PDU or any high-draw device that requires a locking interface for vibration-prone or mission-critical installations. If your load mix includes a large ATS or a secondary distribution panel, this is where it connects.
• (1) NEMA L6-30R Locking Outlet: The L6-30R is a 240V-capable locking receptacle, which matters when your rack includes dual-corded servers or storage arrays with a 208/240V power supply on one cord. Having this outlet on the POD avoids the need for a separate step-up transformer or a second UPS circuit.
• Rack-Mountable Black Enclosure: The unit mounts directly in a standard equipment rack alongside the GXT5 UPS, keeping the power distribution path short and the cabling organized. The black finish matches standard rack hardware. Rackmounting also means the POD stays physically secured — no floor-level trip hazard from a standalone unit.
• GXT5 5kVA–6kVA Exclusive Compatibility: The PD5-001 is engineered specifically for the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN. This is not a universal PDU — the input plug and circuit ratings are matched to those UPS output specifications. If you are deploying any other GXT5 model (2kVA, 3kVA, the HV series, or the 8–10kVA range), a different POD variant is required. See the PD5-002 through PD5-006 and PD5-201/202 for alternate receptacle configurations on the same 5kVA–6kVA chassis.

Integration and Compatibility

The PD5-001 is part of Vertiv's Output POD accessory family for the GXT5 rack UPS line. Compatible UPS models are strictly the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN — confirm your UPS model number before ordering. The POD connects via the NEMA L14-30P plug to the UPS output receptacle; no additional wiring or configuration is required at the POD level.

If your downstream equipment mix differs from the (4) NEMA 5-15/20R + (1) L14-30R + (1) L6-30R layout of the PD5-001, Vertiv offers six additional POD variants (PD5-002 through PD5-006) for the same GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN platforms with different receptacle combinations — including all-locking L5-20R/L5-30R and all-L6-20R configurations. Match the POD to your actual plug inventory before commissioning.

For hardwired installations or IEC receptacle requirements (C13/C19 for international equipment), refer to the PD5-201 and PD5-202 variants, which serve the high-voltage GXT5 models. Consult your UPS and power infrastructure planning resources to verify circuit loading before finalizing the POD selection for your rack.

Frequently Asked Questions

Q: Which UPS models is the PD5-001 compatible with?

A: The PD5-001 is compatible exclusively with the Vertiv GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN UPS systems. It is not compatible with other GXT5 models, including the 2kVA, 3kVA, 8kVA, 10kVA, 15kVA, or 20kVA variants, or the high-voltage (HV) series.

Q: What receptacles does the PD5-001 provide?

A: The PD5-001 provides six output receptacles: four NEMA 5-15/20R duplex outlets, one NEMA L14-30R locking outlet, and one NEMA L6-30R locking outlet. The input is a single NEMA L14-30P locking plug rated at 30A maximum.

Q: Can I use the PD5-001 with a different brand of UPS?

A: No. The PD5-001 is engineered specifically for the Vertiv GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN. The input plug and circuit ratings are matched to those UPS output specifications. Using it with other UPS systems is not a supported configuration.

Q: Is the PD5-001 rack-mountable?

A: Yes. The PD5-001 is designed for rack mounting and installs in a standard equipment rack alongside the GXT5 UPS, keeping the power distribution path short and cabling organized.

Q: What is the maximum current rating of the PD5-001?

A: The PD5-001 is rated for a maximum of 30A, matching the output capacity of the compatible GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN UPS models.

Q: Which PD5 POD variant should I choose if my equipment uses different plugs?

A: Vertiv offers multiple POD variants for the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN: PD5-002 (L6-20R and 5-15/20R mix), PD5-003 (L6-30R and 5-15/20R mix), PD5-004 (L5-20R and L5-30R locking), PD5-005 (L5-20R and L6-30R), and PD5-006 (all L6-20R). Select the variant that matches your downstream equipment plug types.

Ted Perry

The detail that matters most when specifying the PD5-001 is not the outlet count — it is the L6-30R locking outlet. In a 5kVA or 6kVA GXT5 rack, that single 240V locking receptacle is often what determines whether dual-corded servers can draw from both power supplies on protected power, or whether one cord falls back to utility. If your server population is growing toward dual-corded 1U or 2U units, verifying that L6-30R is on your POD before the GXT5 ships saves a truck roll.

Technical Highlights:

• Six-Receptacle Output Mix: Four NEMA 5-15/20R, one NEMA L14-30R, and one NEMA L6-30R from a single L14-30P input — covers both standard and locking load types in one 30A circuit without a separate PDU stage.
• 30A Maximum Current: Matches the rated output of the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN exactly. Size your aggregate load to stay below 30A continuous (80% rule: 24A sustained) to avoid nuisance tripping.
• Exclusive UPS Compatibility: Engineered for GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN only. The L14-30P input and circuit ratings are specific to those models — ordering the wrong POD variant for a different GXT5 kVA rating is the most common commissioning error on this product line.

Deployment Considerations:

• Confirm your UPS model number ends in 5000MVRT4UXLN or 6000MVRT4UXLN before ordering — the PD5 series does not fit the LVRT, HVRT, or 3KL620 variants. The part number similarity across the GXT5 family trips up procurement teams who copy UPS model numbers from asset tags in the field.
• The L6-30R outlet requires a matching L6-30P plug on the connected device. If your current equipment inventory is entirely NEMA 5-15 or 5-20 plugged, the PD5-003 or PD5-005 may be a better fit depending on whether you need the locking L-series outlets at all.

The PD5-001 is the right call for a mixed-load 5kVA or 6kVA GXT5 rack where you need both standard NEMA 5-15/20 outlets for commodity gear and at least one 240V locking receptacle for a dual-corded server or storage array — specifically in enterprise server rooms, edge data closets, and colocation cabinets where receptacle flexibility matters more than a uniform locking-only layout.
