Vertiv PD5-004 GXT5 Output POD — Rack-Mount Power Distribution Unit
Overview
The Vertiv PD5-004 is a rack-mountable Output POD (Power Distribution Unit) designed exclusively for the GXT5 5000VA and 6000VA 4U rack UPS platforms. Where a standard UPS might ship with a fixed outlet configuration that doesn't match your load mix, the PD5-004 lets you tailor downstream connectivity — delivering (4) NEMA L5-20R and (2) NEMA L5-30R receptacles from a single NEMA L14-30P input, all within a 30A maximum current envelope. If your rack contains a mix of 20A and 30A twist-lock loads — think high-density servers, storage arrays, or PDUs fed from the UPS — the PD5-004 gives you the outlet geometry to match without custom wiring.
Key Features
- NEMA L14-30P Input Connector: The single twist-lock L14-30P input connects directly to the corresponding output port on compatible GXT5 UPS models, providing a clean, tool-free mechanical connection that won't vibrate loose in a high-density rack environment. No hardwire termination required for this model.
- (4) NEMA L5-20R Outlets: Four 20A twist-lock receptacles handle the majority of rack equipment — servers, switches, and storage nodes that ship with NEMA L5-20P cords. Having four discrete outlets means you can distribute load across individual devices rather than daisy-chaining strips, which keeps fault isolation clean.
- (2) NEMA L5-30R Outlets: Two 30A twist-lock receptacles give you headroom for power-hungry nodes — high-core-count servers, dense storage shelves, or secondary PDUs — without requiring a separate circuit. These are rated for loads that would otherwise need a dedicated 30A branch.
- 30A Maximum Current: The 30A aggregate ceiling maps directly to the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN output capacity. Staying within this envelope ensures the UPS transfer logic operates correctly and the POD wiring isn't stressed during sustained load or transfer events.
- Rack-Mountable Form Factor: Designed to mount in a standard equipment rack (black finish), the PD5-004 keeps outlet density organized at the UPS tier rather than scattering power strips throughout the rack. This matters for cable management audits and power draw documentation during data center inspections.
- GXT5 Family Integration: The PD5-004 is engineered specifically for the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN — the 5kVA and 6kVA 4U mid-range rack UPS models in the GXT5 line. Using a purpose-built POD rather than a generic PDU preserves the mechanical and electrical interface Vertiv designed into those platforms.
Integration & Compatibility
The PD5-004 (often searched as PD5 004) is compatible with two specific GXT5 UPS models: the GXT5-5000MVRT4UXLN and the GXT5-6000MVRT4UXLN. These are the 5000VA and 6000VA variants in the 4U rack form factor. If your deployment uses a different GXT5 capacity — for example the 3000VA 2U models or the 8000–10000VA high-voltage variants — a different POD part number applies. Consult the full Vertiv GXT5 accessory matrix to confirm the correct POD for your UPS model before ordering; the POD-to-UPS pairing is mechanical and electrical, not just electrical, so mismatches are not field-correctable with adapters.
Within the GXT5-5000/6000 family, Vertiv offers several PD5-series PODs with different outlet configurations. The PD5-001 provides a mix of NEMA 5-15/20R, L6-30R, and L14-30R outlets for heterogeneous load mixes. The PD5-003 emphasizes NEMA L6-30R and 5-15/20R for 208V-capable environments. The PD5-004 is the right choice when your load is entirely 120V twist-lock — specifically when you need both 20A and 30A L5-series receptacles from the same POD. If all loads are 20A, the PD5-002 (four L6-20R plus two 5-15/20R) or PD5-001 may be a better fit depending on voltage requirements. Browse the full power distribution lineup to compare configurations side by side.
Frequently Asked Questions
Q: Which GXT5 UPS models is the PD5-004 compatible with?
A: The PD5-004 is compatible with the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN — the 5000VA and 6000VA 4U rack UPS models in the GXT5 mid-range line. It is not compatible with other GXT5 capacities or form factors.
Q: What outlet types does the PD5-004 provide?
A: The PD5-004 provides (4) NEMA L5-20R and (2) NEMA L5-30R receptacles, all fed from a single NEMA L14-30P input. Maximum aggregate current is 30A.
Q: Can the PD5-004 be used with a different brand of UPS or a non-GXT5 Vertiv UPS?
A: No. The PD5-004 is designed specifically for the GXT5-5000MVRT4UXLN and GXT5-6000MVRT4UXLN. The mechanical and electrical interface is proprietary to those models. Using it with other UPS units is not supported by Vertiv.
Q: Does the PD5-004 require hardwiring or does it use a plug-in connector?
A: The PD5-004 uses a plug-in NEMA L14-30P input connector — no hardwiring required. This distinguishes it from the PD5-003 hardwired variant. Installation involves connecting the L14-30P plug to the UPS output port and rack-mounting the unit.
Q: What is the maximum current rating for the PD5-004?
A: The PD5-004 is rated for a maximum of 30A. This aligns with the output capacity of the compatible GXT5 5000VA and 6000VA UPS models.
Q: How does the PD5-004 differ from the PD5-003?
A: The PD5-003 provides (2) NEMA L6-30R and (4) NEMA 5-15/20R outlets — suited for mixed 120V/208V environments. The PD5-004 provides (4) NEMA L5-20R and (2) NEMA L5-30R outlets — suited for all-120V twist-lock load environments where you need both 20A and 30A receptacles.
The PD5-004 is a straightforward spec-match exercise, but getting it wrong is expensive — wrong POD means a return and possible rack downtime. The critical detail is the output connector mix: four NEMA L5-20R and two NEMA L5-30R, all from a 30A NEMA L14-30P feed. If your GXT5-5000MVRT4UXLN or GXT5-6000MVRT4UXLN is powering a rack where every load uses 120V twist-lock cords and you need a mix of 20A and 30A receptacles in the same POD, this is the correct selection.
Technical Highlights:
- NEMA L14-30P Input: Plug-in connection to the GXT5 output port — no field wiring required, which keeps installation time to minutes rather than a licensed electrician's half-day.
- (4) L5-20R + (2) L5-30R Output Mix: The six-outlet split gives you four slots for standard 20A server and network gear plus two 30A slots for high-draw nodes — a ratio that matches most mid-density rack builds without leaving outlets unused.
- 30A Maximum Current: The 30A ceiling is the aggregate for all six outlets combined. Plan your load distribution accordingly — if the two L5-30R outlets are simultaneously fully loaded at 30A each, you're already over budget. Real-world load diversity usually keeps this manageable, but model it before commissioning.
Deployment Considerations:
- Confirm your UPS is specifically the GXT5-5000MVRT4UXLN or GXT5-6000MVRT4UXLN before ordering. Other GXT5 models (the 3kVA 2U line, the high-voltage 8–10kVA variants, the 15–20kVA models) use entirely different POD part numbers and the connectors are not interchangeable.
- The 30A aggregate limit means you cannot simultaneously run six fully-loaded circuits — plan your load schedule so total draw stays under 30A. A metered PDU downstream of each L5-30R outlet is worth the cost if you're running high-density compute that approaches nameplate wattage.
The PD5-004 fits best in a mid-density 120V rack environment — a colocation cage, a branch office IDF, or a small data room where the GXT5-5000/6000 is the primary UPS and the load mix is all twist-lock 120V equipment at both 20A and 30A cord ratings.
