Scanner Dimensions:
6.6 in. H x 2.6 in. W x 4.2 in. D
Cradle Dimensions:
2.9 in. H x 3.7 in. W x 4.8 in. D
Scanner Weight:
5.4 oz./154 g
Cradle Weight:
6.5 oz./182 g
Drop Specification:
6.0 ft./1.8 m to concrete
Tumble Specification:
2,000 tumbles in 1.5 ft./0.5 m
IP Sealing:
IP42
ESD Discharge:
+/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity:
0 to 9,000 Foot Candles/0 to 96,840 Lux
Input Voltage:
4.5 to 5.5VDC
Bluetooth Radio Standard:
Bluetooth Version 4.0 with BLE
Bluetooth Range Class 1:
330 ft. (100m)
Bluetooth Range Class 2:
33 ft. (10m)
Host Support:
USB, RS232, Keyboard Wedge, TGCS (IBM) 46xx over RS485
Keyboard Support:
Over 90 international keyboards
Battery Type:
2,500 mAh Li-Ion
Scans Per Full Charge:
65,000
Operating Time Per Full Charge:
83 hours
Typical Charge Time:
7 hrs 45 min (USB)
Illumination:
(2) 645nm Red LEDs
Imager Field of View:
48° H x 37° V
Image Sensor:
1,280 x 960 pixels
Minimum Print Contrast:
16% minimum reflective difference
Skew/Pitch Roll Tolerance:
+/- 60°; +/- 60°; 0-360°
Operating Temperature:
32° to 122° F/0° to 50° C
Charging Temperature:
32° to 104° F/0° to 40° C
Storage Temperature:
-40° to 158° F/-40° to 70° C
Humidity:
5% to 95% RH, non-condensing
Electrical Safety:
EN 60950-1, IEC 60950-1, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07
Environmental Compliance:
RoHS EN 50581
LED Safety:
IEC 62471
IT Emissions:
EN 55022 (Class B); EN 55032 (Class B)
IT Immunity:
EN 55024
Harmonic Current Emissions:
EN 61000-3-2
Voltage Fluctuation and Flicker:
EN 61000-3-3
Radio Frequency Emissions:
47 CFR Part 15, Subpart B, Class B
Digital Apparatus Emissions:
ICES-003 Issue 6, Class B
1D Symbology Support:
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32
Digital Watermark Support:
Digimarc
