Dimensions Corded:
6.6 in. H x 2.6 in. W x 4.2 in. D
Dimensions Standard Cradle:
2.8 in. H x 3.3 in. W x 8.3 in. D
Dimensions Presentation Cradle:
2.9 in. H x 3.7 in. W x 4.8 in. D
Weight Corded:
5.4 oz./154 g
Weight Cordless:
8.3 oz./235.3 g
Weight Desk Cradle:
7.1 oz./202 g
Weight Presentation Cradle:
6.5 oz./182 g
Input Voltage Corded:
4.5 to 5.5VDC
Input Voltage Cordless Cradles:
5V: 4.7 to 5.5VDC; 12V: 10.8 to 13.2VDC
Current Corded:
450 mA (typical)
Current Cordless:
470 mA (typical) 12V
Bluetooth Radio Standard:
Bluetooth Version 4.0 with BLE: Class 1
Bluetooth Range:
330 ft. (100m)
Battery Capacity:
2,500 mAh
Battery Type:
Li-Ion
Scans Per Full Charge:
65,000
Operating Time Per Full Charge:
83 hours
Typical Charge Time USB:
7 hrs 45 min
Typical Charge Time BC1.2:
3 hrs
Typical Charge Time 5V Source:
4 hrs 30 min
Typical Charge Time 12V Source:
2 hrs 15 min
Imager Field of View:
48° H x 37° V
Image Sensor:
1,280 x 960 pixels
Minimum Print Contrast:
16% minimum reflective difference
Tolerance Skew/Pitch Roll:
+/- 60°; +/- 60°; 0-360°
Operating Temperature:
32° to 122° F/0° to 50° C
Charging Temperature:
32° to 104° F/0° to 40° C
Storage Temperature:
-40° to 158° F/-40° to 70° C
Humidity:
5% to 95% RH, non-condensing
Drop Specification:
6.0 ft./1.8 m to concrete
Tumble Specification:
2,000 tumbles in 1.5 ft./0.5 m
IP Sealing:
IP42
ESD Discharge:
+/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity:
0 to 9,000 Foot Candles/0 to 96,840 Lux
Electrical Safety:
EN 60950-1, IEC 60950-1, UL 60950-1, CAN/CSA-C22.2
RoHS:
EN 50581
LED Safety:
IEC 62471
IT Emissions:
EN 55022 (Class B); EN 55032 (Class B)
IT Immunity:
EN 55024
Harmonic Current Emissions:
EN 61000-3-2
Voltage Fluctuation and Flicker:
EN 61000-3-3
Radio Frequency:
47 CFR Part 15, Subpart B, Class B
Digital Apparatus:
ICES-003 Issue 6, Class B
Decode Range Code 39 3 mil:
2.2 in./5.6 cm. to 5.0 in./12.7 cm.
Decode Range Code 39 20 mil:
0 in./0 cm. to 36.8 in./93.5 cm.
Decode Range Code 128 3 mil:
2.6 in./6.6 cm. to 4.5 in./11.4 cm.
Decode Range Code 128 5 mil:
1.6 in./4.1 cm. to 8.4 in./21.3 cm.
Decode Range Code 128 15 mil:
0 in./0 cm. to 27.1 in./68.8 cm.
Decode Range PDF 417 5 mil:
2.3 in./5.8 cm. to 6.4 in./16.3 cm.
Decode Range PDF 417 6.7 mil:
1.8 in./4.6 cm. to 8.5 in./21.6 cm.
