Dimensions Corded:
6.6 in. H x 2.6 in. W x 4.2 in. D
Dimensions Cordless:
6.6 in. H x 2.6 in. W x 4.2 in. D
Dimensions Standard Cradle:
2.8 in. H x 3.3 in. W x 8.3 in. D
Dimensions Presentation Cradle:
2.9 in. H x 3.7 in. W x 4.8 in. D
Weight Corded:
5.4 oz./154 g
Weight Cordless:
8.3 oz./235.3 g
Weight Desk Cradle:
7.1 oz./202 g
Weight Presentation Cradle:
6.5 oz./182 g
Drop Specification:
6.0 ft./1.8 m to concrete
Tumble Specification:
2,000 tumbles in 1.5 ft./0.5 m
IP Sealing:
IP42
ESD Discharge:
+/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity:
0 to 9,000 Foot Candles/0 to 96,840 Lux
Input Voltage Corded:
4.5 to 5.5VDC
Input Voltage Cordless Cradle:
5V: 4.7 to 5.5VDC; 12V: 10.8 to 13.2VDC
Operating Current Corded:
450 mA (typical)
Operating Current Cradle:
470 mA (typical) 5V; 743mA (typical) 12V
Bluetooth Radio Standard:
Version 4.0 with BLE: Class 1
Bluetooth Range Class 1:
330 ft. (100m)
Bluetooth Range Class 2:
33 ft. (10m)
Supported Host:
USB, RS232, Keyboard Wedge, TGCS (IBM) 46xx over RS485
Supported Keyboards:
Over 90 international keyboards
FIPS Security Certification:
Compliant with FIPS 140-2
Battery Capacity:
2,500 mAh
Battery Type:
Li-Ion Power Precision+
Scans Per Battery Charge:
65,000
Operating Time Per Full Charge:
83 hours
Typical Charge Time:
7 hrs 45 min (USB)
Aiming Pattern:
Circular 617nm Amber LED
Illumination:
(2) 645nm Red LEDs
Imager Field of View:
48° H x 37° V
Image Sensor:
1,280 x 960 pixels
Minimum Print Contrast:
16% minimum reflective difference
Decode Tolerance Skew/Pitch Roll:
+/- 60°; +/- 60°; 0-360°
Graphics Format Support:
Bitmap, JPEG or TIFF
Image Quality Resolution:
109 PPI on an A4 document
Minimum Element Resolution:
Code 39 - 3.0 mil
Operating Temperature:
32° to 122° F/0° to 50° C
Charging Temperature:
32° to 104° F/0° to 40° C
Storage Temperature:
-40° to 158° F/-40° to 70° C
Humidity:
5% to 95% RH, non-condensing
Electrical Safety:
EN 60950-1, IEC 60950-1, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07
RoHS:
EN 50581
LED Safety:
IEC 62471
IT Emissions:
EN 55022 (Class B); EN 55032 (Class B)
IT Immunity:
EN 55024
Harmonic Current Emissions:
EN 61000-3-2
Voltage Fluctuation and Flicker:
EN 61000-3-3
Radio Frequency Compliance:
47 CFR Part 15, Subpart B, Class B
Digital Apparatus Compliance:
ICES-003 Issue 6, Class B
1D Decode Support:
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32
Digital Watermark Support:
Digimarc
