Scanner Type:
1D/2D Imager
Processor Speed:
800 MHz
Image Sensor Resolution:
1280 x 960 pixels
Scan Range:
Up to 24 in./61 cm
Drop Specification:
6.0 ft./1.8 m to concrete
Tumble Specification:
2,000 tumbles in 1.5 ft./0.5 m
IP Sealing:
IP42
ESD Discharge:
+/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity:
Up to 96,840 Lux
Corded Dimensions:
6.6 in. H x 2.6 in. W x 4.2 in. D
Corded Weight:
5.4 oz./154 g
Cordless Weight:
8.3 oz./235.3 g
Cradle Weight:
7.1 oz./202 g
Input Voltage:
4.5 to 5.5VDC
Bluetooth Radio Standard:
Bluetooth Version 4.0 with BLE
Bluetooth Range:
330 ft. (100m) Class 1
Battery Type:
2,500 mAh Li-Ion
Battery Scans Per Charge:
65,000
Battery Operating Time:
83 hours
Battery Charge Time:
7 hrs 45 min (USB)
Minimum Print Contrast:
16%
Decode Range Code 39:
2.2 in./5.6 cm. to 5.0 in./12.7 cm. (3 mil)
Decode Range Code 128:
2.6 in./6.6 cm. to 4.5 in./11.4 cm. (3 mil)
Decode Range PDF 417:
2.3 in./5.8 cm. to 6.4 in./16.3 cm. (5 mil)
Operating Temperature:
32° to 122° F/0° to 50° C
Storage Temperature:
-40° to 158° F/-40° to 70° C
Operating Humidity:
5% to 95% RH, non-condensing
Electrical Safety:
EN 60950-1, IEC 60950-1, UL 60950-1
RoHS:
EN 50581
LED Safety:
IEC 62471
IT Emissions:
EN 55022 (Class B), EN 55032 (Class B)
IT Immunity:
EN 55024
Radio Frequency Compliance:
47 CFR Part 15, Subpart B, Class B
Digital Apparatus Compliance:
ICES-003 Issue 6, Class B
