Digi International 76002114 3G/4G/5G Multiband Cellular Module
The 76002114 is a multiband cellular module from Digi International covering 3G, 4G, and 5G operating modes across a 6MHz-6000MHz frequency range. It solves a specific integration problem: adding cellular connectivity to a fixed installation — an NVR, gateway, or remote monitoring enclosure — where wired uplink isn't available or isn't reliable enough as a primary path. The 229 x 30.5mm (9.02 x 1.2 in) form factor and direct SMA male mounting point are built for enclosure-panel installs rather than desktop use.
Compatibility
Direct/SMA male mounting means the 76002114 pairs with any host device or enclosure exposing a standard SMA female antenna connection — routers, gateways, and cellular-uplink kits built around that interface. Confirm the host device's supported cellular bands align with the 6MHz-6000MHz range before ordering, since 3G/4G/5G band support varies by carrier and region. This module is a component-level part, not a complete router — it requires a compatible host system to function.
Installation Notes
Operating temperature is rated -40C to 85C (-40F to 185F), so it holds up in unconditioned outdoor cabinets, rooftop enclosures, and unheated equipment closets without a separate climate-controlled housing. The ABS housing (black) and 56.8g weight keep the module light enough that the SMA connection point takes the mechanical load without extra bracket support in most panel-mount setups. Because mounting is direct SMA male, no separate cabling or pigtail is needed between the module and its antenna port — reduces one failure point compared to modules requiring an intermediate cable run. Verify carrier SIM provisioning and any required data plan separately; this module handles the RF/modem hardware layer only.
For broader network planning around cellular-backed installs, see the PoE and network planning guide. If this module is going into a camera-based deployment, pair it with IP cameras from the same Digi International catalog or review PoE switches for the wired side of a hybrid network.
