Vertiv FSC1N001 30A 208V Power Distribution Unit
Overview
The Vertiv FSC1N001 is a 30-amp, 208-volt power distribution unit built for data center and commercial infrastructure environments where reliable, fixed-capacity power delivery is non-negotiable. Fitted with an L6-30P input plug and universal connector output, this PDU drops cleanly into standard raised-floor or overhead power runs without requiring custom wiring adapters. If you're provisioning a rack or row of network gear, surveillance servers, or edge compute equipment at 208V, the FSC1N001 is designed to handle the load without intermediate conversions or plug compatibility headaches.
Key Features
- 30A Capacity at 208V: With 30 amps available at 208 volts, this unit handles the sustained load of fully populated equipment racks — think NVR arrays, PoE switch stacks, or dense server deployments. At 208V, you're drawing less current for the same wattage compared to 120V circuits, which means lower resistive losses over long cable runs and less strain on branch circuit breakers.
- L6-30P Input Plug: The NEMA L6-30P twist-lock input is a standard connection point on 208V commercial UPS outputs and PDU whips. This means the FSC1N001 plugs directly into existing infrastructure in most commercial data center and IDF/MDF closet buildouts — no plug adapters, no field wiring.
- Universal Connector Output: The universal connector output gives you flexibility on the load side, accommodating a range of IEC and standard receptacle types depending on the outlet strip or whip configuration. This matters in mixed-equipment environments where power cord standards vary across vendors.
- 208V Input and Output: Input and output voltage are matched at 208V — there's no voltage step-down or conversion happening here. What comes in goes out at the same potential, which keeps the design simple, efficient, and predictable for load calculations.
- 50/60Hz Dual Frequency Support: Compatible with both 50Hz and 60Hz power infrastructure, the FSC1N001 isn't locked to North American grid standards. This matters if you're deploying in facilities that run 50Hz power or in mixed international environments where grid frequency varies by building or region.
- 60°C Operating Temperature Rating: Rated to operate up to 60°C, this unit tolerates the ambient heat found in enclosed rack environments and poorly ventilated equipment rooms. In practice, most data center hot aisles run well below this ceiling, but the rating gives headroom for high-density deployments without thermal derating concerns.
Integration and Compatibility
The FSC1N001 is built around standard commercial power infrastructure. The L6-30P input aligns with the output receptacles found on most 208V single-phase UPS units, including Vertiv's own Liebert line, making it a natural fit for Vertiv-anchored power chains. On the load side, the universal connector output accommodates downstream distribution to rack PDU strips or direct equipment connections. The 208V pass-through design requires no neutral — it runs on a two-hot 208V circuit, which is standard in three-phase commercial electrical panels. For integrators building out surveillance NVR rooms or PoE switch infrastructure, pairing this unit with a compatible Vertiv UPS and downstream metered PDU strip gives you a clean, auditable power chain from wall to rack.
Frequently Asked Questions
Q: What input plug does the FSC1N001 use?
A: The FSC1N001 uses a NEMA L6-30P twist-lock input plug, which is the standard 30A 208V locking connector found on most commercial UPS output whips and power panels.
Q: What is the output voltage of the FSC1N001?
A: The output voltage matches the input at 208V. There is no voltage conversion — this is a pass-through PDU that distributes 208V directly to connected loads.
Q: Can the FSC1N001 be used on 50Hz power grids?
A: Yes. The FSC1N001 supports both 50Hz and 60Hz input frequency, making it compatible with international power infrastructure as well as standard North American 60Hz commercial facilities.
Q: What is the maximum operating temperature for the FSC1N001?
A: The FSC1N001 is rated to operate up to 60°C, which provides sufficient thermal headroom for use in enclosed rack environments and high-density equipment rooms.
Q: What type of output connector does the FSC1N001 provide?
A: The FSC1N001 provides a universal connector output on the load side, offering flexibility for connecting a range of IEC and standard receptacle configurations.
Q: Is the FSC1N001 suitable for use with Vertiv Liebert UPS systems?
A: The L6-30P input plug on the FSC1N001 is compatible with standard 208V single-phase UPS output receptacles, including those found on Vertiv Liebert systems, making it a straightforward fit in Vertiv-anchored power chains.
The FSC1N001 is a purpose-built 208V pass-through PDU and the spec that defines its fit is the 30A capacity on an L6-30P input — if your facility panel or UPS has L6-30 outputs and you're running 208V loads, this is a direct connection with no adapter chain between your power source and your equipment. That's a smaller detail than it sounds: every adapter in a power chain is a potential failure point and a voltage drop you have to account for in load calculations.
Technical Highlights:
- 30A / 208V Capacity: At 208V single-phase, 30A gives you up to 6.24kVA of available capacity before you hit the 80% continuous-load derate — approximately 4.99kW for sustained use. That's enough headroom for a fully loaded 2U NVR plus a managed PoE switch stack without budgeting into the red.
- L6-30P Twist-Lock Input: The NEMA L6-30P is the de-facto standard output receptacle on 208V commercial UPS whips. Matching it here means the FSC1N001 lands in an existing power chain without field modification — a real time-saver during rack buildouts where schedule pressure is high.
- 60°C Operating Temperature: Most equipment rooms and enclosed rack environments run 25–40°C at the intake; the 60°C ceiling on the FSC1N001 gives you a 20°C+ safety margin even in poorly ventilated spaces, which is relevant in smaller IDF closets that lack precision cooling.
Deployment Considerations:
- The FSC1N001 runs on a two-hot 208V circuit with no neutral required — verify your panel circuit configuration before installation. A mismatched 120V/neutral circuit will not deliver the correct voltage to connected equipment.
- The universal connector output type should be confirmed against your specific downstream load connectors before ordering — 'universal' does not mean unlimited compatibility, and the output configuration should be validated against your PDU strip or equipment cord specs.
The FSC1N001 is a practical fit for commercial security infrastructure rooms and IDF closets where the power panel already delivers 208V on L6-30 circuits and the goal is a clean, no-conversion feed to NVR racks or PoE switch infrastructure — particularly in Vertiv Liebert UPS environments where the upstream and downstream components share a common ecosystem.
