Digital Watchdog DWC-XSBA08Mi vs Geovision TBL8810-0010: Specification Comparison
Both the Digital Watchdog DWC-XSBA08Mi and the Geovision TBL8810-0010 are 8MP outdoor IR bullet cameras targeting commercial and perimeter surveillance installations. This comparison evaluates how each performs across imaging capability, environmental and installation requirements, and integration with VMS platforms and edge analytics. The DW unit provides a dense specification set; the Geovision listing is notably sparse, and where specs are absent that gap is called out explicitly rather than assumed.
In This Guide
How do the imaging specs compare?
The DWC-XSBA08Mi is built on a 1/2.8-inch 4K CMOS sensor with a total pixel count of 3864×2228 and an active resolution of 3840×2160. Its Star-Light Plus sensor achieves 0.09 lux in color and 0.0 lux in black-and-white, and it carries a True WDR rating of 120 dB. IR range is specified at 140 feet via Smart IR. The Geovision TBL8810-0010 is listed as an 8MP IR bullet with IR illumination and automatic day/night switching, but its sensor size, exact minimum illumination value (noted only as 'super low lux'), IR range, and WDR decibel rating are not provided in the available specifications — only 'WDR Pro' and 'WDR' labels appear.
Lens flexibility differs substantially. The DWC-XSBA08Mi ships with a 2.7–13.5mm motorized varifocal lens with auto-focus and P-iris control, delivering a horizontal field of view of 90.3° at wide and 33.1° at telephoto, a meaningful advantage for installations where coverage angle must be tuned after mounting. The TBL8810-0010 is listed with a 4.3mm fixed focal length and a claimed 4.3× optical zoom; however, a fixed 4.3mm lens and a 4.3× optical zoom are contradictory descriptors and cannot both be accurate — buyers should verify the actual lens configuration directly with Geovision before specifying this camera.
What about installation and environment?
The DWC-XSBA08Mi carries IP67 ingress protection and IK10 vandal resistance in an aluminum die-cast bullet housing weighing 2.64 lbs (1.2 kg) with dimensions of 12.2″ × 3.81″ (310 × 97 mm). Operating temperature is specified at −40°F to 122°F (−40°C to 50°C), making it suitable for cold-climate deployments. Power draw is DC 12V at max 13.2W/1.1A or PoE at 14.8W, placing it in PoE Class 4 (802.3af/at). The TBL8810-0010 carries no IP or IK rating, no operating temperature range, no housing material, no weight, and no dimension data in the provided specifications. Its PoE support is referenced in card copy as '802.3af/at' but is not confirmed in the structured spec fields. Mounting options are listed as wall, eave, and pole.
For installers, the absence of an IP/IK rating on the Geovision unit means environmental suitability cannot be verified from spec data alone. The DW camera's −40°C lower bound and IK10 rating are directly confirmed figures that can be cited in project submittals.
Which fits your VMS and analytics better?
The DWC-XSBA08Mi is ONVIF-compliant and is explicitly listed as compatible with DW Spectrum, Genetec, and Milestone, in addition to any ONVIF-compliant VMS. It supports dual-stream H.264/H.265/MJPEG up to 30fps at 3840×2160, with H.265 network resolution topping out at 3840×2160 and MJPEG capped at 1920×1080. The camera includes one audio input (1.0Vms, 3KΩ) and one audio output with G.711 compression, plus one alarm input and one alarm output. On-board storage supports Micro SD/SDHC/SDXC up to 1TB. Edge analytics are extensive: intrusion detection, line crossing, tailgating, direction, dwell, counting, zones, logical rules, and tamper, among others. Operational notifications cover email, FTP, alarm output, and SD card.
The TBL8810-0010 is listed as ONVIF-compliant and AI-based analytics are noted, but no specific analytic functions are enumerated. Audio capability, alarm I/O, and on-board storage are not specified. H.265 compression is confirmed. VMS compatibility is described only as 'ONVIF-compliant systems' without named platform validation. Buyers requiring audio recording, specific analytic types, or named VMS certification should seek supplemental documentation from Geovision.
Which should you choose: the DWC-XSBA08Mi or the TBL8810-0010?
Our take: The DWC-XSBA08Mi is the stronger choice when specification confidence, verified environmental ratings, and edge analytics depth are required. Three concrete spec deltas illustrate the gap: the DW camera's IR range is documented at 140 feet versus no stated range for the TBL8810-0010; its WDR is confirmed at 120 dB True WDR versus an unquantified 'WDR Pro' label; and its operating temperature is verified to −40°F versus no temperature rating provided for the Geovision unit. The DW unit's 2.7–13.5mm motorized varifocal also offers post-mount flexibility that a 4.3mm fixed lens cannot match. The TBL8810-0010 may be adequate for cost-sensitive deployments on Geovision-native NVR infrastructure where full spec disclosure is obtained through Geovision documentation, but it cannot be competitively evaluated against the DW camera from available data alone.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | Digital Watchdog DWC-XSBA08Mi | Geovision TBL8810-0010 |
|---|---|---|
| Resolution | 8MP (3840 × 2160) | 8MP (resolution not numerically confirmed in specs) |
| Image Sensor | 1/2.8" 4K CMOS, Star-Light Plus | — |
| Lens / Focal Length | 2.7–13.5mm motorized varifocal, auto-focus, P-iris | 4.3mm (zoom descriptor inconsistent — verify with manufacturer) |
| Horizontal FOV | 90.3° (wide) ~ 33.1° (tele) | — |
| Min. Illumination | 0.09 lux (color) / 0.0 lux (B/W) | Super low lux (no numeric value specified) |
| IR Range | 140 ft Smart IR | — |
| Wide Dynamic Range | 120 dB True WDR | WDR Pro (dB value not specified) |
| Max Frame Rate | Up to 30fps at all resolutions | — |
| Video Compression | H.265, H.264, MJPEG | H.265 |
| IP Rating | IP67 | — |
| IK / Impact Rating | IK10 | — |
| Operating Temperature | −40°F to 122°F (−40°C to 50°C) | — |
| Power Input / PoE | DC 12V (max 13.2W) or PoE 14.8W, Class 4 | PoE 802.3af/at (from card copy only — not in structured specs) |
| Edge Storage | MicroSD/SDHC/SDXC up to 1TB | — |
| Audio I/O | 1 input / 1 output, G.711 | — |
| Alarm I/O | 1 input / 1 output | — |
| ONVIF | Yes | Yes |
| Named VMS Compatibility | DW Spectrum, Genetec, Milestone | ONVIF-compliant systems (no named platforms) |
| Edge Analytics | Intrusion, line crossing, tailgating, counting, direction, dwell, logical rules, tamper, and more | AI-based (no specific functions enumerated) |
| Dimensions | 12.2" × 3.81" (310 × 97 mm) | — |
| Weight | 2.64 lbs (1.2 kg) | — |
| Housing Material | Aluminum die-cast | — |
| Warranty | 5 years | — |
Frequently Asked Questions
Which should you choose: the DWC-XSBA08Mi or the TBL8810-0010?
The DWC-XSBA08Mi is the stronger choice when specification confidence, verified environmental ratings, and edge analytics depth are required. Three concrete spec deltas illustrate the gap: the DW camera's IR range is documented at 140 feet versus no stated range for the TBL8810-0010; its WDR is confirmed at 120 dB True WDR versus an unquantified 'WDR Pro' label; and its operating temperature is verified to −40°F versus no temperature rating provided for the Geovision unit. The DW unit's 2.7–13.5mm motorized varifocal also offers post-mount flexibility that a 4.3mm fixed lens cannot match. The TBL8810-0010 may be adequate for cost-sensitive deployments on Geovision-native NVR infrastructure where full spec disclosure is obtained through Geovision documentation, but it cannot be competitively evaluated against the DW camera from available data alone.
Is the DWC-XSBA08Mi or TBL8810-0010 better for low-light performance?
Based on available specs, the DWC-XSBA08Mi is documented at 0.09 lux in color and 0.0 lux in black-and-white with a 140-foot Smart IR range. The TBL8810-0010 describes its low-light capability only as 'super low lux' with no numeric illumination value and no stated IR range, so a direct lux-to-lux comparison cannot be made from provided specifications.
Can either camera integrate with third-party VMS platforms like Milestone or Genetec?
The DWC-XSBA08Mi is explicitly listed as compatible with DW Spectrum, Genetec, and Milestone, and is ONVIF-compliant. The TBL8810-0010 is listed as ONVIF-compliant, which provides a baseline level of interoperability, but no named third-party VMS certifications are included in its available specifications.
Which camera is better suited for harsh outdoor environments with extreme temperatures or vandalism risk?
The DWC-XSBA08Mi carries confirmed IP67 ingress protection, IK10 vandal resistance, and an operating temperature range of −40°F to 122°F (−40°C to 50°C) in an aluminum die-cast housing. The TBL8810-0010 has no IP rating, no IK rating, no operating temperature range, and no housing material listed in its available specifications, making it impossible to assess suitability for harsh environments from spec data alone.
