Comnet Commercial Grade 52 Port Gbps Managed Switch 48 10/100/1000Mbps TX Ports - CWX52F24T48MP

Comnet CWX52F24T48MP Commercial-Grade 52-Port Managed Switch

Overview

The Comnet CWX52F24T48MP is a 19-inch rack-mountable managed switch built for surveillance and enterprise network deployments requiring PoE distribution across dozens of cameras, access readers, or wireless access points. With 48 Gigabit Ethernet ports (10/100/1000 Mbps) equipped with PoE and 4 dedicated 1G/10G SFP+ uplink ports, this unit handles both edge-device power and high-bandwidth backhaul in a single form factor. The internal dual power supply eliminates single points of failure in power delivery—critical when your surveillance network cannot tolerate downtime. TAA compliance confirms sourcing from approved vendors for federal and state procurement environments.

Compatibility

The CWX52F24T48MP integrates with any standard IP camera, access control reader, wireless AP, or network device operating at 10/100/1000 Mbps over Ethernet (RJ-45). The 48 PoE ports support standard 802.3af/at powered devices up to the switch's per-port and aggregate power budgets—verify your device wattage against the switch datasheet before deployment. The 4 SFP+ ports accept 1G or 10G optics for fiber uplinks or copper 10G connections to core switches, NVRs, or backbone infrastructure. Managed VLAN and QoS features allow segmentation of camera traffic from access-control and office networks, improving security posture and reducing broadcast storms.

Installation Notes

Mount in a standard 19-inch equipment rack with adequate ventilation; do not block intake/exhaust vents. Connect the dual power supplies to separate circuit branches or UPS units to ensure redundancy—a single supply failure will not drop the entire switch. Use quality RJ-45 cables (Cat5e minimum; Cat6 preferred for longer runs). Configure management IP, VLAN assignments, and port PoE budgets before deployment; default factory state may not match your network topology. Firmware updates are available from the manufacturer—check periodically for security patches.

What's in the Box

• 1x Comnet CWX52F24T48MP managed switch
• Dual power cables (region-specific)
• Documentation and quick-start guide
