Comelit 1440 VIP 6-Port PoE Switch
Overview
The Comelit 1440 VIP is a 6-port managed PoE switch engineered to centralize power and data distribution in compact surveillance and IP intercom deployments. Built around Gigaport architecture, it delivers simultaneous bandwidth for multiple 4MP video streams without external power injectors — a real advantage when you're deploying in wall cabinets or small control rooms where space and power overhead matter. The 1440 supports both wall-mounted and rack-mount configurations, making it practical for residential, small commercial, and distributed intercom installations where traditional industrial switches would be overkill.
Key Features
- 802.3af PoE per port: Each of the six ports delivers up to 13W via standard 802.3af, sufficient to power typical fixed IP cameras and Comelit intercom endpoints without requiring a separate PoE injector or external power supply. This keeps installation simpler and reduces cable clutter.
- Gigaport backbone: One-gigabit switching fabric ensures that multiple simultaneous 4MP streams won't compete for bandwidth. In practice, six fixed cameras at 4MP and 30 fps will consume roughly 600–900 Mbps depending on codec and compression, leaving headroom for redundancy and intercom traffic.
- Managed switching: VLAN, QoS, and port mirroring capabilities let you segment video traffic, prioritize intercom signaling, and mirror ports to a connected recorder or NVR — essential when integrating with Comelit IP cameras or third-party ONVIF devices.
- Compact form factor: Wall-mounted or rack-mountable design fits into tight spaces — critical for retrofit installations in existing intercom cabinets or residential panel enclosures.
- Dual power input (optional): Supports redundant power for installations requiring high availability, though standard single-input operation covers most small deployments.
- Silent operation: Fanless design produces no acoustic noise — important in residential or office environments where the switch sits in visible or adjacent spaces.
Integration & Compatibility
The 1440 integrates natively with Comelit video intercom systems and any ONVIF-compliant IP camera. Managed switch features enable straightforward integration with network video recorders and video management software — configure port mirroring to send a copy of video traffic to an NVR without consuming additional bandwidth on the switch itself.
When planning a deployment, verify that your cameras and endpoints meet 802.3af power budgets. Six simultaneous 13W draws consume the full 78W PoE budget, leaving no margin. If you need to add additional devices or run longer cable runs (which increase power loss), consider whether a higher-wattage PoE switch variant would better suit your growth plan. For most compact installations — wall-mounted residential intercom with 3–4 cameras, or a small commercial entrance vestibule — the 1440 is right-sized.
When to Choose a Different Model
If your deployment requires more than six devices, higher per-port power (PoE+ or PoE++ for PTZ cameras or heated housings), or you're integrating with larger industrial networks, consider a higher-port-count or higher-wattage variant within the Comelit or alternative managed switch family. The 1440 is optimized for compact, fixed-camera scenarios — not scalability.
Frequently Asked Questions
Q: Can I use the Comelit 1440 to power a heated outdoor camera housing?
A: Standard heated housings typically require 25–40W. The 1440 delivers 13W per port via 802.3af. You would need an external power supply for the heater, or upgrade to a PoE+ switch that supports higher wattages.
Q: Does the 1440 support VLAN tagging?
A: Yes. As a managed switch, it supports 802.1Q VLAN configuration. This allows you to isolate video traffic from intercom signaling or management traffic if required.
Q: What's the maximum cable run length from the 1440 to a camera?
A: Standard Gigabit Ethernet supports up to 100 meters (328 feet) from switch to device. Beyond that, signal quality degrades and PoE power loss increases; use a dedicated PoE extender or additional switch segment.
Q: Can I daisy-chain multiple Comelit 1440 switches?
A: Yes, by connecting one uplink port from each switch to another switch or network. However, this reduces the number of available PoE ports on each unit; plan your topology carefully to avoid bottlenecks.
Q: Is there a redundant power option for the 1440?
A: Check the datasheet or contact Comelit directly. Some managed switch variants support dual power inputs; the standard 1440 configuration may be single-input only.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Comelit 1440 is purpose-built for distributed, fixed-camera scenarios where you need managed switching and PoE centralization without industrial overhead. If you're specifying this for a 4MP intercom and camera deployment, you're making a deliberate choice to optimize for compactness and simplicity — not scalability. The 1440 shines in residential retrofit and small commercial installations where space, noise, and upfront cost matter more than future expansion.
Technical Highlights:
- 802.3af budget of 78W total: With six ports at 13W max, you can run six cameras simultaneously, but only if they're in the sub-13W class. A single camera drawing more than 13W will either underperform or require external power — plan your endpoint selection before committing to the switch.
- Gigaport switching fabric: Six simultaneous 4MP streams at 30 fps will consume roughly 600–900 Mbps of that gigabit backplane. You have headroom, but if you're adding a mirror port to an NVR or intercom traffic on the same switch, bandwidth contention is possible. Segment your network if video and signaling are competing.
- Managed switching with VLAN and QoS: You can isolate intercom signaling from video or create separate VLANs for management. This is not a dumb switch — you have granular control, but it requires configuration knowledge. Don't assume it's a plug-and-play device.
Deployment Considerations:
- The 1440 is wall-mount or rack-mount, but verify the enclosure dimensions and cooling before assuming it fits your cabinet. Fanless design is quiet but passive cooling has limits — keep ambient temperatures in the 0–50°C range.
- A common gotcha: PoE power loss over long cable runs (>80 meters). If your site requires runs approaching 100 meters, budget 2–3W of power drop and verify that your cameras tolerate voltage sag. Better to plan for shorter runs or add a mid-span injector.
The 1440 is the right choice for a residential multi-unit intercom retrofit with 3–4 fixed entrance cameras, or a small office vestibule requiring centralized power and video isolation. It's not right for sprawling warehouse automation or scalable enterprise deployments — those demand higher port counts and higher-wattage budgets. Scope your endpoint count and power profile first, then commit.
