Camden CX-DE1217 2" Angle Bracket for Magnetic Lock

Overview

The CX-DE1217 is a 2" angle bracket designed to mount magnetic lock strikes in multi-door access control installations. Use this when you need structural support to securely attach a magnetic lock strike to a door frame or jamb in proximity reader–based systems. The bracket provides the rigid mounting geometry required for delayed egress magnetic locks operating at 24VDC, particularly the CX-DE1200 series locks.

Compatibility

The CX-DE1217 is engineered for the Camden CX-DE1200 series delayed egress magnetic locks and compatible strike mounting scenarios in 4-door access control deployments. Works with proximity credential reader systems and 24VDC magnetic lock control circuits. Fits installations where you are integrating a magnetic strike with standard access control wiring and door position monitoring, typical in healthcare, retail, and institutional environments running compliance-driven delayed egress logic.

Installation Notes

Mount the bracket using the pre-drilled attachment points to the door frame or structural jamb element. Ensure all fasteners achieve proper torque to prevent vibration-induced loosening over months of door cycling. The 2" form factor accommodates standard North American door frame widths and strike pocket depths. Verify that your mounting surface can accept the bracket's bolt pattern before ordering—confirm door thickness and frame material (steel vs. aluminum) with your installer. Position the bracket so the magnetic lock strike hangs vertically with no side-load that could degrade holding force or cause misalignment with the keeper plate.

What's in the Box

• 1x CX-DE1217 2" angle bracket
