Form Factor:
Dome
Resolution:
1920x1080 (Full HD)
WDR:
Forensic WDR (up to 120 dB)
IR Distance:
0.02 lux @ 30 IRE F1.2
Video Compression:
H.264
Lens Type:
3.6mm F2.0 fixed, M12 mount
Mount Type:
Ceiling; M12 fixed-iris mount
Frame Rate:
30fps
Image Sensor Size:
1/2.9 inch Progressive Scan RGB CMOS
Min Illumination:
0.04 Lux color
Storage Capacity:
1024MB
VMS Compatibility:
ONVIF-compatible platforms
Features:
Digital PTZ; Pan ±30°; Tilt 15-90°; Rotation ±175°; Preset positions; Guard tour; Control queue
Type:
Dome
Product Type:
Dome
Warranty:
5 Year(s)
Compatibility:
ONVIF
Operating System:
Windows
Night Vision:
IR
Power Type:
PoE+
PoE Class:
1
IP Rating:
IP66
Resolution MP:
2MP
Focal Length:
3.6mm
Built In IR:
Yes
Day Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
Secure Boot:
Yes
HTTPS Encryption:
Yes
Weight Lbs:
0.53
Wide Dynamic Range:
Forensic WDR (up to 120 dB)
HFOV:
88°
Housing Color:
White
Environment Rating:
Indoor
Mounting:
(Probe Dependant)
Lightfinder:
Lightfinder
Max Frames Per Second:
45
Aperture:
2.0 / 2.0 / 1.5
Digital Pan/Tilt:
Yes
Digital Zoom:
Yes
Zipstream:
Yes
H.264:
High, Main
H.265:
Yes
Active Tampering:
Yes
AXIS Camera Application Platform:
Yes
IEEE 802.1X:
Yes
Signed OS:
Yes
Local Storage (memory Card Slot:
Yes
Operating Temperature:
-30 to 55 °C
Vandal Rating:
IK10
Variants:
AXIS P3905-R Mk III RJ45 3.6 mm AXIS P3905-R Mk III M12 3.6 mm AXIS P3905-R Mk III M12 2.8 mm
Minimum Focus Distance:
0.3 m (1 ft) M12 mount, fixed iris 2.8 mm , F1.2 :; 0.3 m (1 ft) M12 mount, fixed iris See Optional accessories for exchangeable lenses
Minimum Illumination Color:
0.02 lux at 30 IRE F1.2; 0.04 lux at 30 IRE F2.0; 0.07 lux at 50 IRE F1.2; 0.13 lux at 50 IRE F2.0 2.8 mm , F1.2 :
Camera Adjustment Pan:
±30°
Camera Adjustment Tilt:
15-90°
Camera Adjustment Rotation:
±175°
Model:
S6LM55
Video Streaming:
Up to 4 unique and configurable video streams Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264 and H.265 Video streaming i
Noise Reduction:
Spatial filter (2D noise reduction) Temporal filter (3D noise reduction)
Image Settings Scene Profiles:
forensic, vivid, traffic overview
Image Processing:
Axis Zipstream, Forensic WDR, Lightfinder
Pan/Tilt/Zoom:
Digital PTZ, preset positions, guard tour, control queue
Network Protocols:
IPv4, IPv6 USGv6, HTTP, HTTPS , HTTP/2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, PTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH,
Application Programming Interface:
Open API for software integration, including VAPIX® and AXIS Camera Application Platform (ACAP); specifications at axis.com/developer-community . One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S and ONVIF® Profile T, s
Video Management Systems:
Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, AXIS Camera Station 5, and video management software from Axis’ partners available at axis.com/vms .
Onscreen Controls:
Video streaming indicator Wide dynamic range Privacy masks
Event Conditions Device Status:
above operating temperature, above or below operating temperature, below operating temperature, IP address removed, network lost, new IP address, storage failure, system ready, within operating temperature
Event Conditions Edge Storage:
recording ongoing, storage disruption
Event Conditions I/O:
manual trigger, virtual input MQTT subscribe
Scheduled And Recurring:
scheduled event
Event Conditions Video:
average bitrate degradation, live stream open, tampering
Upload Images Or Video Clips:
FTP, HTTP, HTTPS, SFTP, email and network share
Event Actions Notification:
HTTP, HTTPS, TCP and email Overlay text Preset positions
Event Actions Record Video:
SD card and network share SNMP trap messages WDR mode MQTT publish
Built-in Installation Aids:
Pixel counter
Included:
AXIS Video Motion Detection, active tampering alarm
Supported:
AXIS Fence Guard, AXIS Loitering Guard, AXIS Motion Guard Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/ acap
Product Markings:
CE, ECE, KC, RCM, UL/cUL, UKCA, VCCI, WEEE
Supply Chain:
TAA compliant NDAA compliant
Australia/New Zealand:
RCM AS/NZS CISPR 32 Class A
EMC Canada:
ICES-3(A)/NMB-3(A)
EMC Japan:
VCCI Class A,
EMC Korea:
KS C 9835, KS C 9832 Class A,
EMC USA:
FCC Part 15 Subpart B Class A
EMC Rolling Stock:
EN 50121-3-2, EN 50121-4, IEC 62236-4
Safety:
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, UN ECE R118 EN 45545-2, NFPA 130
Cybersecurity:
ETSI EN 303 645
Edge Security Software:
Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 Client Credential Flow/OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption
Edge Security Hardware:
Axis Edge Vault cybersecurity platform Secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit)
Network Security:
IEEE 802.1x (EAP-TLS, PEAP-MSCHAPv2) , IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS , TLS v1.2/v1.3 , Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Documentation:
AXIS Hardening Guide AXIS Vulnerability Management Policy AXIS Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/ cybersecurity/resources To read more about Axis cybersecurity support,
Casing:
IP66/67- and IK10-rated aluminum and polycarbonate casing
Connectors RJ45:
male, 10BASE-T/100BASE-TX
Connectors M12:
female, rugged, D-coded with rotatable coupling nut All connectors support PoE
Maximum (intermittent:
70 °C (158 °F)
Operating Conditions Humidity:
10-100% RH (condensing)
Dimensions Height:
50 mm (1.97 in), ø 110 mm (4.33 in)
Box Content:
Camera, Installation guide, Windows decoder 1-user license, lens tool
Lenses:
Lens M12 2.1 mm, F2.2: horizontal field of view 145° Lens M12 2.8 mm, F1.2: horizontal field of view 107° Lens M12 3.6 mm, F2.0 : horizontal field of view 88° Lens M12 6 mm, F1.6: horizontal field of view 51° Lens M12 8 mm, F1.6: horizontal field of
Other:
AXIS T94D01S Mount Bracket, AXIS T94D02S Curved Mount Bracket, Network coupler IP66, Network cable coupler indoor, TM3101 Pendant Wall Mount, AXIS TP3826-E housing, TP3827 Clear Dome Cover, TP3830 Top Black Cover For more accessories, see axis.com/p
System Tools:
AXIS Site Designer, AXIS Device Manager, product selector, accessory selector, lens calculator Available at axis.com
Languages:
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Part Numbers:
Available at axis.com/products/axis-p3905-r-mk- iii#part-numbers
Substance Control:
PVC free, BFR/CFR free RoHS in accordance with EU RoHS Directive 2011/65/ EU/ and EN 63000:2018 REACH in accordance with (EC) No 1907/2006. For SCIP UUID, see axis.com/partner.
Recycled Aluminum:
95% Screened for conflict minerals in accordance with OECD guidelines To read more about sustainability at Axis, go to axis. com/about-axis/sustainability
Environmental Responsibility:
axis.com/environmental-responsibility Axis Communications is a signatory of the UN Global Compact, read more at unglobalcompact.org
DORI Detect:
DORI definition: 25 px/m (8 px/ft); Distance: 41.3 m (135 ft); DORI definition: 25 px/m (8 px/ft); Distance: 50.6 m (166.0 ft)
DORI Observe:
DORI definition: 63 px/m (19 px/ft); Distance: 16.4 m (53.8 ft); DORI definition: 63 px/m (19 px/ft); Distance: 20.1 m (65.9 ft)
DORI Recognize:
DORI definition: 125 px/m (38 px/ft); Distance: 10.1 m (33.1 ft); DORI definition: 125 px/m (38 px/ft); Distance: 8.2 m (27 ft)
DORI Identify:
DORI definition: 250 px/m (76 px/ft); Distance: 4.0 m (13 ft); DORI definition: 250 px/m (76 px/ft); Distance: 5.1 m (16.7 ft)
Country of Origin:
Poland
UNSPSC:
46171610
