ASUS G700TF-XS776 G Series Desktop Black Core Ultra 7 265F 32GB NV RTX5070 1TB M.2 2280 PCIE G4 SSD

ASUS G700TF-XS776 G Series Tower Desktop — Core Ultra 7 265F, RTX 5070, Win 11 Pro

Overview

The ASUS G700TF-XS776 is a high-performance tower desktop built around Intel's Core Ultra 7 265F processor and NVIDIA's GeForce RTX 5070 GPU — a pairing that positions it well beyond typical office workstations and into territory suited for GPU-accelerated VMS analytics, video decoding at scale, AI inference workloads, and demanding simulation or rendering pipelines. At 40.39 lb and 9.45 x 20.05 x 18.88 in, this is a full-size tower: plan rack or floor space accordingly. The G700TF-XS776 (often searched as G700TF XS776) ships with Windows 11 Pro, 32GB of system RAM, and a 1TB M.2 2280 PCIe Gen 4 SSD — a complete, deployable workstation platform out of the box.

Key Features

• Intel Core Ultra 7 265F — 20-Core Hybrid Architecture: The 265F combines 8 Performance cores (up to 5.2 GHz turbo) and 12 Efficient cores (up to 4.6 GHz turbo) for a total of 20 cores and 20 threads. The hybrid layout means background tasks — OS operations, network I/O, logging — offload to E-cores, leaving P-cores fully available for compute-intensive work like real-time video transcoding or analytics inference. The 30 MB Smart Cache keeps frequently accessed data close to the die, reducing memory latency on repetitive decode loops.
• Up to 5.3 GHz Boost, 65W Base TDP: The 265F's base power envelope is 65W, but maximum turbo power reaches 182W under sustained load. In practice this means the system can sustain peak single-thread performance for burst workloads — license plate recognition, motion search, export rendering — without requiring exotic cooling infrastructure. Size your UPS for the 182W ceiling if runtime during outages matters.
• Intel AI Boost NPU: The integrated Neural Processing Unit offloads AI inference tasks from both the CPU and GPU. For deployments running on-device analytics — object classification, anomaly detection, smart search — the NPU handles lighter inference models without pulling GPU resources away from display or encode pipelines. This matters when the RTX 5070 is already occupied driving high-resolution outputs or running parallel decode streams.
• NVIDIA GeForce RTX 5070: The RTX 5070 brings current-generation GPU compute to the platform. For VMS workstations running GPU-accelerated decode (e.g., Milestone XProtect with hardware acceleration enabled, Genetec Security Center), the RTX 5070 can handle simultaneous high-resolution stream playback that would saturate a CPU-only decode path. It also supports CUDA-based analytics pipelines and AI model inference workloads that benefit from dedicated VRAM and tensor cores.
• 32GB System RAM: 32GB is the practical floor for running a full VMS client, background services, and analytics simultaneously without paging. It supports multi-monitor operator stations, simultaneous live view and playback sessions, and moderate virtual machine workloads if you need isolated environments for security software.
• 1TB M.2 2280 PCIe Gen 4 SSD: PCIe Gen 4 storage delivers sequential read/write throughput roughly double that of Gen 3 drives — important when loading large video exports, launching GPU-heavy applications, or running databases for access control or analytics platforms. The M.2 2280 form factor also leaves SATA ports and drive bays free for additional bulk storage expansion if local video archiving is required.
• PCIe + Ethernet Interfaces: The G700TF-XS776 provides both PCIe expansion and Ethernet connectivity. PCIe slots support additional capture cards, GPU upgrades, or specialized I/O cards for integrators who need hardware-level video input or serial communication with legacy systems. Ethernet provides the network backbone for connecting to NVRs, access control servers, and management platforms without relying on Wi-Fi.
• Windows 11 Pro: The Pro license matters in enterprise and commercial environments — it includes BitLocker drive encryption, Group Policy management, Remote Desktop, and Hyper-V. These are not optional features for deployments where the workstation handles sensitive recorded footage or sits on a domain-joined corporate network.

Integration & Compatibility

The G700TF-XS776 is positioned as a VMS workstation or analytics server in physical security deployments. Its PCIe interface supports expansion cards required by some NVR and video management platforms. Ethernet connects directly to PoE switches, NVRs, and access control servers on the security network. Windows 11 Pro is compatible with the major commercial VMS platforms that require GPU-accelerated decode. The Intel Core Ultra 7 265F's NPU is also compatible with Windows AI platform APIs, enabling integration with AI-powered security analytics tools built on Microsoft's AI stack. For integrators building out a network video recorder environment or a GPU-accelerated VMS workstation station, this tower provides the compute headroom to grow into higher channel counts without immediately requiring a server-class platform. Pair it with a managed PoE network switch to keep the security LAN isolated from corporate traffic — a standard practice in commercial installations. For camera selection guidance relevant to what this workstation will display and record, the IP camera catalog covers the full range of compatible endpoints. Additional ASUS compute platforms are available for deployments requiring varied form factors or processing profiles.

Frequently Asked Questions

Q: What processor is in the ASUS G700TF-XS776?

A: The G700TF-XS776 uses an Intel Core Ultra 7 265F — a 20-core (8 Performance + 12 Efficient), 20-thread processor from Intel's Core Ultra Series 2 generation, with a maximum boost frequency of 5.3 GHz and 30 MB Smart Cache.

Q: What GPU does the G700TF-XS776 include?

A: It ships with an NVIDIA GeForce RTX 5070, a current-generation discrete GPU suited for GPU-accelerated video decode, AI inference, and multi-display output in VMS and analytics workstation deployments.

Q: Does the G700TF-XS776 come with Windows 11 Pro?

A: Yes. The G700TF-XS776 ships with Windows 11 Pro, which includes BitLocker encryption, Group Policy management, Remote Desktop, and Hyper-V — features required in most commercial and enterprise security environments.

Q: What storage does the G700TF-XS776 include, and can it be expanded?

A: The system includes a 1TB M.2 2280 PCIe Gen 4 SSD as the primary drive. The tower form factor provides additional drive bays and interfaces for bulk storage expansion, making it suitable for deployments that need local video archiving alongside the OS and application drive.

Q: What does the Intel AI Boost NPU in the G700TF-XS776 do?

A: The Intel AI Boost NPU is a dedicated neural processing unit integrated in the Core Ultra 7 265F. It offloads AI inference workloads — such as object detection or classification — from the CPU and GPU, allowing the RTX 5070 to remain available for video decode and display tasks simultaneously.

Q: How heavy is the G700TF-XS776, and what are its dimensions?

A: The G700TF-XS776 weighs 40.39 lb and measures 9.45 in (L) x 20.05 in (W) x 18.88 in (H). Plan floor or rack shelf placement accordingly — this is a full-size tower, not a small-form-factor system.

Ted Perry

The G700TF-XS776 stands out in VMS workstation builds primarily because of the 265F's 182W maximum turbo power budget paired with the RTX 5070 — that combination gives you genuine GPU-accelerated decode headroom for high-channel-count live view without the cost or complexity of a rack server. Most integrators underspec the workstation end of a camera system and then wonder why their VMS client stutters at 32+ streams; this machine is built to avoid that problem.

Technical Highlights:

• 20-Core Hybrid CPU (8P + 12E cores): The P-core/E-core split means background OS and network tasks don't compete with the decode pipeline. P-cores stay available for latency-sensitive work at up to 5.2 GHz while E-cores handle housekeeping at up to 4.6 GHz — a real operational advantage on a machine running 24/7 with multiple processes active.
• 30 MB Smart Cache: On repeated video decode and database query patterns — both common in VMS workstation use — a large L3 cache reduces main memory round-trips. This translates to more consistent frame delivery during simultaneous live view and playback sessions compared to cache-starved configurations.
• PCIe Gen 4 NVMe SSD: The 1TB PCIe Gen 4 drive delivers high sequential throughput for fast application load times and video export operations. More practically, it keeps the OS and application layer snappy even under concurrent workloads, which matters when operators are running live view, playback, and search simultaneously on a single workstation.

Deployment Considerations:

• At 40.39 lb and 18.88 in tall, the G700TF-XS776 is a floor-standing or dedicated-shelf tower. Budget physical space in your operations center or server room accordingly — it will not fit a standard 1U or 2U rack slot without a purpose-built tower shelf.
• The 265F's maximum turbo power is 182W and the RTX 5070 adds its own power draw on top of that. Size the UPS and PDU circuit for the combined system peak, not the 65W base TDP. Undersizing the UPS is the most common oversight in workstation deployments.

For a multi-operator security operations center running a GPU-accelerated VMS platform at 32–64+ camera channels, the G700TF-XS776 delivers the processor headroom, GPU compute, and storage I/O to serve as the primary analyst workstation without immediately requiring a server-class chassis upgrade.
