APC by Schneider Electric AP8866 - Power Distribution Unit - Rack-mountable - 208 V 3 Phase - 6 IEC

APC by Schneider Electric AP8866 Rack-Mount Power Distribution Unit

Overview

The AP8866 is a 208V 3-phase rack-mount power distribution unit from the APC by Schneider Electric lineup, built for high-density equipment racks where single-phase circuits fall short. With 15 outlets and 36 receptacle positions across a 3-phase configuration, it distributes load evenly across phases — reducing the risk of circuit overloads that trip breakers and take down an entire rack mid-operation. The black 2.2-inch form factor is designed for rack-mount environments where U-space is at a premium. If you're powering a dense mix of NVRs, managed switches, and edge compute nodes from a single distribution point, the AP8866 handles that load profile without requiring multiple smaller PDUs. Model number AP8866 ships in a standard rack-mount configuration at 208V — confirm your facility's 3-phase feed before ordering, as this unit is not compatible with standard 120V single-phase circuits.

Compatibility

Designed for standard 19-inch equipment racks accepting a rackmount PDU form factor. The 208V 3-phase input is suited to commercial and enterprise environments fed by dedicated 3-phase electrical panels — typical in data centers, server rooms, and large-scale security operations centers running high-draw equipment. The IEC receptacle configuration (36 positions) accommodates IEC C13/C19 power cords standard on rack-mount servers, network switches, NVRs, and video management appliances. Verify cord type against your specific equipment before deployment — NEMA-standard devices require a separate adapter or replacement cord. Output voltage is 208V; equipment rated only for 120V requires a step-down transformer and is not directly compatible.

Installation Notes

Mount horizontally in a standard 19-inch rack using the integrated rack-mount ears. The 6-foot cord provides reach to a nearby 3-phase PDU or floor-mounted distribution panel — plan your rack-to-panel distance before finalizing rack placement. Balance load across all three phases at installation to avoid asymmetric draw, which can degrade upstream panel efficiency and trip phase-specific breakers under peak load. Eccn classification 5A992 applies for export compliance if shipping internationally.
