APC by Schneider Electric Rack PDU 2G Metered Zerou 17.2KW 208V (24) C13 & (24) C19 - AP8866X837

APC by Schneider Electric AP8866X837 Rack PDU 2G Metered Zerou 17.2KW 208V (24) C13 & (24) C19

Overview

The APC by Schneider Electric AP8866X837 is a 2G Metered Rack Power Distribution Unit (PDU) designed for high-density IT environments. It provides granular, per-outlet power monitoring, allowing you to track power consumption at the device level. This is critical for capacity planning, load balancing, and identifying potential power issues before they impact critical infrastructure. The AP8866X837 is suitable for 208V networks and delivers up to 17.2KW of power, supporting environments with substantial equipment loads.

Compatibility

This Rack PDU is designed for integration into standard 19-inch server racks. It is compatible with APC's EcoStruxure IT management platform and StruxureWare Data Center Expert software for centralized monitoring and control. While not specific to any single server or network vendor, its standard C13 and C19 outlets accommodate a wide range of IT equipment, including servers, switches, storage arrays, and other rack-mounted devices commonly found in enterprise data centers and colocation facilities.

Installation Notes

The AP8866X837 requires a 208V, 3-phase power input connection. It features a NEMA L6-30P input plug. Ensure your facility's electrical infrastructure can support the PDU's maximum load capacity of 17.2KW. For optimal performance and safety, it is recommended to install the PDU vertically in a standard rack. Torque specifications for the input power connection should be followed according to local electrical codes and APC's installation guidelines.

What's in the Box

• 1x APC AP8866X837 Rack PDU
• 1x Serial Configuration Cable
• 1x Installation Guide
• 1x Rack Mounting Hardware Kit
