Frame Rate:
30fps
Sensor Type:
1/2.7" Progressive Scan CMOS
Max. Resolution:
1920 × 1080
Min. Illumination:
0.01 Lux (F1.2, AGC ON)
Shutter Time:
1 s to 1/100,000 s, support slow shutter
Day & Night:
IR cut filter
Angle Adjustment:
Tilt: 0° to 75°; Pan: -30° to 30°; Rotate: 0° to 360°
Focal Length & FOV:
2.8mm (100°H/53°V), 4mm (91°H/49°V), 6mm (60°H/32.5°V)
Lens Mount:
M12
Supplement Light Range:
10 m
Main Stream:
1920×1080 @ 25-30 fps
Sub-Stream:
25 fps @ 704×576, 24 fps @ 704×480
Third Stream:
2.8mm lens, 25 fps, 1920×1080
Video Compression:
H.265+/H.265/H.264+/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline profile/Main Profile/High profile
H.265 Type:
Main Profile
Region Of Interest (ROI:
Support 4 fixed region for each stream, and dynamic tracking
Target Cropping:
Yes
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64 Kbps (G.711) / 16 Kbps (G.722.1) / 32-128 Kbps (MP2
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Network Storage:
Support Micro SD/SDHC/SDXC card (up to 128 GB) local storage and NAS (NFS,SMB/CIFS), ANR
Image Settings:
Rotate mode, saturation, brightness, contrast, etc., adjustable by client software or web browser
Day/Night Switch:
Auto/Schedule/Triggered by Alarm In
Wide Dynamic Range (WDR:
120 dB
Image Enhancement:
BLC/ 3D DNR/Defog
Picture Overlay:
Logo overlay, 128×128, 24-bit BMP
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Micro SD up to 128 GB
Alarm:
1 alarm input, 1 alarm output
Basic Event:
Motion detection, tampering alarm, exception (HDD full, HDD error, network disconnected, IP address conflicted, illegal login）
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection;Face detection, scene change detection, defocus detection
Power Type:
PoE
Material:
316L and anti-corrosion coating
Dimension:
Φ 113 × 77.3 mm (4.45" × 3.04")
Package Dimension:
257 × 167 ×145 mm (10.12" × 6.57" × 5.71")
Weight:
1680 g (3.7 lb.)
Startup And Operating Conditions:
-30 to +60°C,
General Function:
Mirror, anti-flicker, heartbeat, watermark, password protection, privacy mask
EMC:
FCC: FCC-SDoC(ANSI C63.4,FCC Part15 sub B);CE: CE-EMC(EN 50130-4:2011+A1:2014,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013);RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3,AS/NZS CISPR 32:2015;IC: IC-VoC(ICES-003 Issue 7:2020);KC: KN 301489-1,KN 301
Safety:
UL: UL 60950-1:2014,CAN/CSA C22.2 No. 60950-1-07:2014;CB: IEC 60950-1
Environment Rating:
CE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863)
Protection:
IP67
Anti-Corrosion Protection:
NEMA-4X, C5-M, 720H salt spray
Housing Color:
White
