Frame Rate:
30fps
Sensor Type:
1/2.8" Progressive Scan CMOS
Min. Illumination:
0.005 Lux (Color), 0 Lux (IR)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355° , tilt: 0° to 75°, rotate: 0° to 355°
Focus:
Fixed
Lens Type:
2.8/4/6/8/12 mm
Field of View:
108° (2.8mm) to 25° (12mm)
Aperture:
F1.6
Lens Mount:
M12
IR Distance:
Up to 30 m
Wavelength:
850nm
Max. Resolution:
1920 × 1080
Main Stream:
50/60fps up to 1920×1080
Sub Stream:
25-30fps, up to 640×480
Third Stream:
30fps 1920×1080 (60Hz)
Video Compression:
H.265/H.264, H.265/H.264/MJPEG, H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Region Of Interest (ROI:
Fixed ROI, main + sub-stream
Audio Compression:
G722.1/G.711/G726/MP2L2/PCM/MP3
Audio Bit Rate:
8-320 Kbps (MP3), 64 Kbps (G.711)
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Chrome 57.0+, Firefox 52.0+, Safari 11+, IE8+
Day/Night Switch:
Day/Night/Auto/Schedule
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
On-Board Storage:
Built-in microSD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Smart Event:
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
Face Detection:
Yes
Exception Detection:
Scene change detection
Firmware Version:
V5.5.80
General Function:
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Startup And Operating Conditions:
-30°C to +60°C, 95% humidity
Power Type:
12 VDC ± 25%, 6 W, PoE(802.3af, 36 V to 57 V, class 3), 7 W
Camera Dimension:
Φ111 × 82.4mm (4.4" × 3.2")
Camera Weight:
Camera: 500 g (1.1 lb.)
Housing Color:
White
