Panduit LCC400-12-6 400KCMIL Lug 2 Hole 1/2 Stud
Overview
The Panduit LCC400-12-6 is a 400KCMIL copper lug designed for terminating large gauge conductors in power distribution and industrial control panels. It features two 1/2" stud holes, providing a robust and reliable connection point for equipment requiring multiple secure attachments. This lug is engineered for applications where high current capacity and dependable termination are critical, such as in power feeders for surveillance systems or automation equipment.
Compatibility
This lug is designed to terminate 400KCMIL conductors. The 1/2" stud holes are compatible with standard 1/2" studs found on switchgear, busbars, and power distribution blocks. It is suitable for use with Panduit's LCC series of lugs and other components designed for 400KCMIL wire.
Installation Notes
For optimal performance and safety, use a Panduit LCC400-12-6 lug with the appropriate Panduit crimping die (e.g., P24, P25, or P29) and a Panduit hydraulic tool. Ensure the conductor is fully inserted into the barrel and that the crimp is properly formed. Torque the 1/2" stud holes to the equipment manufacturer's specification, typically between 250-300 in-lbs, to ensure a secure electrical connection and prevent loosening under vibration.
What's in the Box
- 1x Panduit LCC400-12-6 Lug
