Panduit CJ5E88TGRD Concise Descriptor

Overview

The Panduit CJ5E88TGRD is a red, Category 5e RJ45 connector designed for reliable network terminations in structured cabling systems. This 8-position, 8-wire connector is essential for ensuring clean, professional installations where cable color-coding or identification is critical, such as in security deployments where specific network runs need to be easily distinguished. It supports data transmission up to 1 Gigabit Ethernet, making it suitable for IP camera networks and other data-intensive applications.

Compatibility

This connector is designed for use with standard Category 5e unshielded twisted pair (UTP) bulk cable. It is compatible with most standard RJ45 crimping tools and punch-down tools used for network cable termination. While not specific to any single camera brand, it is suitable for terminating network cables feeding any IP surveillance device that requires a standard RJ45 network connection.

Installation Notes

For optimal performance and signal integrity, ensure the cable jacket is stripped to the correct length to allow the connector's internal strain relief to properly grip the cable. Use a certified Category 5e or higher punch-down tool to seat the wires into the IDC (Insulation Displacement Connector) terminals. A torque specification of 20-30 inch-pounds is recommended for securing the connector to the cable jacket, preventing movement and maintaining consistent electrical contact.
