Middle Atlantic 14SP Cabinet Frame RK 20D - CFR-14-20

Middle Atlantic CFR-14-20 14U In-Cabinet Frame Rack

Overview

The Middle Atlantic CFR-14-20 is a 14U in-cabinet rack frame designed to mount inside an existing enclosure rather than stand alone. With 20 inches of usable depth and a 250 lb UL-rated load capacity, it handles dense AV and security equipment — NVRs, managed switches, patch panels, and power distribution — without the weight overhead of a full enclosure. The CFR-14-20 ships at 20.5 lbs, so it adds minimal structural load when dropped into a wall cabinet or on-wall enclosure. TAA-compliant and manufactured in the USA, it qualifies for federal and government procurement where country-of-origin documentation is required.

Compatibility

The CFR-14-20 is engineered for Middle Atlantic's CFR (Cabinet Frame Rack) series and is sized to integrate with Middle Atlantic wall-mount and on-wall enclosures that accept a 14U frame insert. The 19.25-inch overall width and 10-32 threaded rack rails follow EIA-310 standard spacing, making it compatible with any 10-32 rack-mount equipment — including 1U/2U NVRs, PoE network switches, and 1U security appliances. The 20-inch usable depth accommodates mid-depth rack-mount gear; verify your deepest unit clears the frame before ordering. Consult Middle Atlantic's rack and enclosure accessories line for matching lacing bars, blanks, and cable management panels that fit this frame.

Installation Notes

The flat black powder-coat steel frame installs inside a host enclosure — it is not a freestanding unit. Confirm the host cabinet's interior clear width accepts 19.25 inches and its interior depth accepts the 25.43-inch overall frame height when oriented horizontally (some narrow on-wall enclosures are depth-constrained). The 14U usable height of 24.5 inches means standard 1U blanking panels and equipment will sit flush. Use 10-32 rack screws and cage nuts (not included) for equipment mounting. Weight capacity is 250 lbs UL-listed — account for total installed equipment mass before commissioning.
