i-PRO WVCL934 1/2" CCD Day/Night IP Camera
Overview
The WVCL934 is a compact 1/2" CCD day/night camera built for facilities needing reliable monochrome surveillance at ultra-low light levels without burning storage on thermal or high-megapixel alternatives. At 0.008 lux in B/W mode (F1.4), it captures usable detail in near-total darkness—the appeal for vaults, loading docks, stairwells, and perimeter corridors where you need evidence-grade footage with minimal ambient light. The interline transfer CCD sensor and switchable IR cut filter deliver stable, noise-reduced imagery across both color (0.09 lux) and monochrome modes, eliminating the need for separate night-vision cameras or expensive IR illumination in very dark spaces.
Compatibility
The WVCL934 is a standalone compact camera, not a lens or mount accessory. It pairs with optional C-mount varifocal or fixed lenses (WV-LZ80/2, 2x, 6x, or 10x motorized zoom variants sold separately). It integrates into IP surveillance networks supporting standard protocols and is suitable for retrofit into most enterprise VMS platforms. No specific firmware or driver dependencies are documented; confirm ONVIF compliance with your VMS vendor before integration.
Installation Notes
The WVCL934 operates on 24V AC or 12V DC—check your facility's camera power infrastructure before purchase. ABF (Auto Back Focus) simplifies focus calibration during installation without manual adjustment. Dimensions are 70 mm (W) × 65 mm (H) × 151 mm (D), enabling discrete mounting in ceiling domes or wall enclosures. Peak mode and 8×6-zone BLC (Back Light Compensation) are available for scenes with strong backlighting (sun-facing windows, reflective surfaces). Electronic shutter ranges from 1/100 to 1/10,000 sec, allowing fine-tuned exposure control in mixed lighting. Adaptive 2D/3D DNR (Digital Noise Reduction) reduces grain in low-light footage without introducing motion blur artifacts typical of aggressive temporal filtering.
What's in the Box
- 1× Operating Instructions
- 1× AC Power Cord
