Sensor Type:
1/2.7" Progressive CMOS
Resolution:
SD: 1280 x 960, HD: 2560 x 1920
Lens Types:
Motorized, Vari focal, Remote Focus
Focal Length:
f= 2.8 ~ 10 mm
Aperture:
F1.8(W) ~ F2.74(T)
Iris:
Fixed iris
Field of View:
95°-41° horizontal, 69°-31° vertical
Camera Movement:
Pan 350° Tilt: 80° Rotate:±175°
Shutter Speed:
1/5 sec. to 1/32,000 sec.
Day/Night:
Yes
IR Cut Filter:
Yes
IR Distance:
30 meters
Minimum Illumination:
0.06 Lux (Color), 0.01 Lux (B/W), 0 Lux (IR)
Onboard Storage:
256GB microSD/SDHC/SDXC
Frame Rate:
15FPS
Video Streaming Settings:
HD 2560x1920@15fps, SD 1280x960@15fps
Audio Support:
One way Audio
Effective Range:
5 meters
Audio detection:
Yes
Tampering detection:
Yes
People Analytics:
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Vehicle Analytics:
Intrusion/Line crossing/Loitering detection
Object Analytics:
Unattended object detection, Missing object detection
Input Voltage:
IEEE 802.3af PoE Class 0
Power (Max:
Max: 12.3W (IR on), Max: 9.9W (IR off)
Connectivity:
RJ 45 cable connector for 10/100 Mbps PoE network connection
RTSP:
RTSP/RTP/RTCP, WebRTC
Users:
6 simultaneous users
Security:
Secure boot, Signed firmware, HTTPS/TLS encryption, Video encryption
Interface:
10 Base T/100 Base TX Ethernet (RJ 45)
Operating Temperature:
40°C ~ 60°C (IR off), 40°C ~ 50°C (IR on)
Humidity:
98% RH (non condensing)
Features:
EMC: CE (EN55032, EN55024 Class A, EN50121 4 ), FCC (FCC Part 15 Subpart B Class A), RCM (AS/NZS CISPR32 Class A), VCCI (VCCI CISPR 32 Class A); Safety: UL (UL62368 1), CB (IEC/EN 62368 1, IEC/EN 60950 22, IEC/EN 62471); Environment: IK10 (IEC 62262)
Warranty:
120 month
Included Accessories:
Quick installation guide, alignment sticker, screw pack
Weight:
610g
Dimensions:
Ø 129 x 94 mm
Body:
Metal
Type:
Dome
Product Type:
Dome
Power Type:
PoE
Night Vision:
IR
Housing Color:
White
