Model:
IB9388-HT
CPU:
Multimedia SoC (System-on-Chip)
Flash:
128 MB
RAM:
512 MB
Sensor Type:
1/2.7" Progressive CMOS
Max. Resolution:
2560x1920 (5MP)
Lens Type:
Motorized, Vari-focal, Remote Focus
Focal Length:
f= 2.8 ~ 12 mm
Aperture:
F1.4 ~ F2.8
Iris Type:
Fixed iris
Field of View:
90°-30° horiz, 65°-23° vert, 115°-38° diag
Shutter Time:
1/5 sec. to 1/32,000 sec.
WDR Technology:
WDR Pro
Day/Night:
Yes
Removable IR-cut Filter:
Yes
IR Illuminators:
IR Illuminators, 30m range
Minimum Illumination:
0.035 Lux (Color) /
Tilt Range:
90°
Rotation Range:
180°
Pan/Tilt/Zoom Functionalities:
ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
Storage Capacity:
MicroSD/SDHC/SDXC, NAS compatible
Built-in Installation Aids:
Remote focus, remote zoom
Video Compression:
H.265, H.264, MJPEG
Maximum Frame Rate:
20 fps @ 2560x1920
Maximum Streams:
3 video streams (Up to 8 configurable profiles)
S/N Ratio:
67 dB
Dynamic Range:
120 dB
Video Streaming:
Adjustable resolution & bit rate control
Image Settings:
General settings: video title and time stamp overlay, video orientation (flip, mirror, rotation), day/night settings; Illuminators: illuminators, anti-overexposure; Image settings: white balance, image adjustment (brightness, contrast, saturation, sh
Users:
Live viewing for up to 10 clients
Security:
Access list, digest authentication, HTTPS, IEEE 802.1x, password protection, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), user access log, user account management
Protocols:
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP
Connectivity:
Wired
Compatibility:
ONVIF Profile S, T
Analytics:
Five-window video motion detection
VADP Package:
Trend Micro IoT Security + VIVOCloud
Event Trigger:
Camera tampering, motion detection, manual trigger
Event Action:
Email, HTTP, FTP, NAS, SD card, push notification
Connectors:
RJ-45 cable connector for 10/100Mpbs Network/PoE connection
Input Voltage:
IEEE 802.3af PoE Class 0
Power (Max:
Max. 12.95 W/9 W (IR on/off)
Dimensions:
85 x 85 x 214.5 mm
Weight:
738 g
Features:
EMC: CE (EN 55032 Class B, EN 55024), FCC (FCC Part 15 Subpart B Class B), RCM (AS/NZS CISPR 32 Class B), VCCI (VCCI-CISPR 32 Class B); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471); Environment: IK10 (IEC 62262), IP66 (
Operating Temperature:
-30°C to 60°C
Humidity:
90%
Operating System:
Microsoft Windows 10/8/7; Mac 10.12 (Chrome only)
Web Browser:
Chrome 58.0 or above; Internet Explorer 10/11
Other Players:
VLC: 1.1.11 or above
Packing Contents:
Quick install guide, alignment sticker, screws, cable
Frame Rate:
30fps
Housing Color:
White
