Ubiquiti UXG-PRO-US Next-Generation Gateway
Overview
The Ubiquiti UXG-PRO-US is a compact enterprise-class gateway engineered for branch offices, remote sites, and distributed networks where space and power are constraints. Measuring 98 × 98 × 30 mm and weighing just 302g, this device consolidates WAN termination, LAN distribution, and centralized management into a single polycarbonate enclosure. The UXG-PRO-US draws only 10W via USB Type-C power—meaning it runs off a standard wall adapter with no dedicated power infrastructure—and pairs a dual-core ARM Cortex-A53 processor running at 1 GHz with integrated UniFi cloud management. This matters for branch deployments where you cannot justify a full-size rackmount appliance but still need professional-grade routing, security, and failover logic.
Key Features
- Dual-WAN architecture: Two WAN ports—one 1 GbE RJ45 and one 10G SFP+—enable automatic failover and load-balancing across ISP or MPLS circuits. The SFP+ port supports fiber uplinks, so you're not locked into copper; the RJ45 handles legacy circuits. This design eliminates single points of failure in critical branch locations.
- 10G SFP+ uplink: The SFP+ port delivers 10 Gbps throughput to your core network or data center, reducing latency and bandwidth bottlenecks for bandwidth-heavy applications like video surveillance, large file transfers, or SD-WAN tunnels. Standard gigabit ports would throttle performance in high-traffic sites.
- LAN-side flexibility: Two LAN ports—one 1 GbE RJ45 and one 10G SFP+—allow you to split local traffic into copper (for standard PoE cameras and access points) and fiber (for high-speed switching to your core). This eliminates the need for a separate switch in many deployments.
- WiFi 6 (802.11ax): Integrated WiFi 6 support means the UXG-PRO-US can serve as a wireless gateway when paired with compatible UniFi access points. WiFi 6 delivers higher throughput and lower latency than 802.11ac, reducing congestion in dense deployments—particularly valuable in retail or campus environments where you need both wired cameras and wireless client traffic on a single gateway.
- UniFi cloud management: Web and mobile access to the UniFi Network Application eliminates a separate management plane. You configure failover policies, firewall rules, and traffic shaping from the same dashboard that manages your cameras and access points. Multi-site deployments no longer require different tools for each device class.
- Low power footprint: 10W consumption via USB Type-C power means you can deploy this in closets, cabinets, or remote shelters where 110V outlets are available but running a full power distribution infrastructure is impractical. Thermal output is minimal, so fanless operation and passive cooling are achievable in most climates.
- Compact form factor: 98 × 98 × 30 mm footprint permits wall-mounting, shelf placement, or rackmount via standard accessories—no dedicated rack space consumed. Critical for space-constrained branch locations or multi-tenant buildings where floor space commands premium costs.
- NDAA compliance: CE, FCC, IC, and Anatel certifications (21391-23-08356) qualify the UXG-PRO-US for regulated deployments, including government contracts and enterprises with export control or supply-chain restrictions. This avoids costly redesigns or procurement delays later.
- Operating range: Rated for -10 to 45°C, the device handles unheated closets, outdoor network enclosures, and tropical data centers without thermal throttling or shutdown—important for branch deployments where climate control is secondary.
Integration & Compatibility
The UXG-PRO-US integrates natively with Ubiquiti IP cameras, UniFi access points, and network video recorders through the UniFi Application. Cloud Key Plus deployments benefit from centralized policy application across wired and wireless infrastructure. Standard RJ45 and SFP+ cabling connect to legacy switching or fiber uplinks without vendor lock-in at the physical layer. Dual-WAN logic supports automatic failover, load-balancing, and traffic-shaping policies configured entirely within the UniFi UI—no CLI required for baseline deployments. If you're already managing UniFi cameras or access points, the UXG-PRO-US consolidates gateway functions without introducing a separate management plane, reducing operational overhead.
When to Choose a Different Model
If your branch requires more than two WAN circuits or advanced routing protocols (OSPF, BGP), consider a higher-capacity Ubiquiti gateway in the UniFi Dream Machine or UniFi Network Appliance lineup. If WiFi 6 client offloading is not required and cost is the primary driver, a traditional managed switch with a separate, smaller gateway appliance may reduce overall spend. If you need PoE power injection on LAN ports to support cameras without a separate PoE injector or switch, verify your upstair switching architecture—the UXG-PRO-US does not inject PoE directly.
What's in the Box
- 1x Ubiquiti UXG-PRO-US gateway unit
- 1x USB Type-C power adapter (5V, 3A)
Frequently Asked Questions
Q: Does the UXG-PRO-US support SD-WAN architectures?
A: Yes. The dual-WAN ports and cloud-managed policy engine (UniFi Application) enable SD-WAN deployment. You configure tunnel priorities, failover logic, and application-level traffic shaping directly within the UniFi UI. Integration with third-party SD-WAN controllers requires ONVIF or REST API bridging—verify with your SD-WAN vendor before deployment.
Q: Can I use the UXG-PRO-US in a -10°C environment?
A: Yes. The device is rated for -10 to 45°C operating temperature, making it suitable for unheated closets and outdoor network shelters common in remote branch deployments. No active heating is required below -10°C; thermal stress may occur above 45°C without supplemental cooling.
Q: What is the maximum throughput on the 10G SFP+ port?
A: The 10G SFP+ port delivers up to 10 Gbps throughput. Real-world performance depends on processor load and firewall/IDS policies enabled in the UniFi Application. For sustained full-line-rate traffic on both WAN and LAN, test with your specific ruleset before production deployment.
Q: Is the UXG-PRO-US suitable for outdoor mounting?
A: The device is not rated IP67 or higher, so direct rain exposure is not recommended. Mounting in an outdoor rated enclosure (NEMA 3 or better) is advisable. The -10 to 45°C operating range permits outdoor closets or weatherproof cabinets with passive ventilation.
Q: Does the UXG-PRO-US inject PoE power on its LAN ports?
A: No. The LAN RJ45 and SFP+ ports are data-only. To power PoE cameras or access points, use a separate PoE injector, PoE switch, or managed switch with integrated PoE budget. Plan your LAN topology accordingly if branch sites require dozens of PoE devices.
Q: What certifications does the UXG-PRO-US carry?
A: The device carries NDAA compliance and certifications from CE, FCC, IC, and Anatel (Brazilian regulatory authority, certification 21391-23-08356). This qualifies it for government contracts and regulated enterprise deployments where supply-chain compliance is mandatory.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The UXG-PRO-US (often searched as UXG PRO US) solves a real density problem in distributed branch deployments. A 10W, 98 × 98 mm footprint that handles 10 Gbps uplink traffic without a separate PoE injector or rackmount infrastructure is a genuine win for integrators managing fifty-plus branch sites. The dual-WAN architecture eliminates ISP failover latency in retail or warehouse environments where network outages translate directly to lost revenue.
Technical Highlights:
- 10G SFP+ uplink and dual-WAN ports: Fiber-capable WAN termination paired with automatic failover means your branch no longer relies on a single copper ISP circuit. SFP+ ports also side-step copper distance limitations; many branch closets are further than 100m from the ISP handoff.
- Sub-15W power consumption via USB Type-C: Standard 5V/3A adapter—no 12VDC or 48VDC supplies needed. Deploy in closets where power distribution is ad-hoc; thermal dissipation is negligible, eliminating HVAC concerns in tight spaces.
- Cloud-managed failover and traffic shaping: Dual-WAN policies configured in the UniFi UI, not a CLI. Load-balancing across ISP circuits and automatic carrier-detection reduce engineering overhead per site when you're managing hundreds of branches.
- NDAA compliance: CE, FCC, IC, and Anatel certifications (21391-23-08356) clear government contracts and regulated procurement without redesign delays or supplier audits.
Deployment Considerations:
- LAN ports do not inject PoE. If your branch cameras require power, plan a separate PoE switch or injector upstream of the UXG-PRO-US. This adds cost and floor space if your site design assumed PoE from the gateway.
- Processor is ARM Cortex-A53 1 GHz—adequate for routing and basic IDS/DPI on small-to-medium traffic volumes, but not for crypto-heavy workloads (IPSEC site-to-site tunnels at line rate). Test with your specific firewall ruleset before production.
- Operating range -10 to 45°C means unheated closets work, but outdoor wall-mounting requires an enclosure. Budget NEMA 3 or better cabinets if you're deploying in exterior network rooms.
Position the UXG-PRO-US as the gateway for branch consolidation or warehouse automation edge sites where you need WAN failover, integrated WiFi 6, and cloud management—but your total branch equipment footprint cannot justify a full-size appliance. Retail chains, logistics networks, and multi-tenant office buildings see the most ROI.
