The Hanwha XNV-A9084R/KEX delivers 8MP resolution with advanced IR night vision in a rugged, vandal-resistant dome form factor designed for demanding outdoor security deployments.
Image quality is underpinned by 8MP native resolution paired with WDR (Wide Dynamic Range) technology to handle challenging lighting conditions—from bright sunlight to low-light environments. The camera features dual IR capability with 850nm infrared and integrated Day/Night functionality, enabling 24/7 surveillance without compromise. Advanced compression options include H.265, H.264, and MJPEG, allowing flexible bandwidth and storage optimization across network infrastructure. The varifocal lens with P-iris (IR corrected) provides precise focus adjustment and automatic iris control to maintain consistent exposure across varying light levels and focal distances.
Built for harsh outdoor environments, the XNV-A9084R/KEX carries an IP66 rating for complete dust and water protection, and an IK10 rating providing exceptional resistance to physical impact and vandalism. The aluminum housing with white finish integrates seamlessly into modern architectural settings while delivering industrial-grade durability. Operating temperatures range from -40°C to +50°C, with storage capability from -50°C to +60°C, making it suitable for extreme climates from arctic to tropical installations. The compact dome design accommodates multiple mounting options—wall, ceiling, pole, or corner—enabling flexible camera placement across diverse facility layouts.
Power delivery is simplified through PoE (IEEE 802.3af, Class 3), eliminating the need for dedicated electrical infrastructure and reducing installation complexity. Network integration leverages ONVIF compliance (Profiles S/G/T/M) with metal-shielded RJ-45 10/100BASE-T connectivity, ensuring compatibility with mainstream VMS platforms and security ecosystems. Onboard processing includes 4GB RAM and 8GB eMMC storage, with firmware protection via encrypted boot, secure boot, and signed firmware mechanisms to safeguard against unauthorized access and tampering.
The camera supports audio input for two-way communication scenarios, and the 85-character title display capability aids in event logging and multi-camera coordination. These specifications make the XNV-A9084R/KEX well-suited for retail environments, transportation hubs, critical infrastructure, and perimeter security applications requiring both image clarity and ruggedized construction.
- 8MP resolution with WDR for high-detail imaging in mixed lighting
- IR night vision (850nm) with Day/Night functionality for continuous monitoring
- IP66 and IK10 ratings—dust-sealed and vandal-resistant
- PoE powered (802.3af) with simplified installation
- Varifocal P-iris lens for precise focus and light control
- ONVIF compatible with H.265/H.264/MJPEG codec support
The XNV-A9084R/KEX is a solid choice for outdoor sites where both image quality and physical durability matter. The IK10 vandal rating and IP66 weatherproofing handle abuse and exposure reliably, while 8MP resolution and IR deliver practical 24/7 monitoring. PoE 802.3af power keeps cabling simple, and ONVIF support ensures it integrates without proprietary lock-in. Best suited for facilities that prioritize uptime and low maintenance over cutting-edge AI analytics.
