STI KIT-SA505 Key Switch Mounting Bracket for SA5000 Series (view 2)
STI KIT-SA505 Key Switch Mounting Bracket for SA5000 Series (view 2)
STI KIT-SA505 Key Switch Mounting Bracket for SA5000 Series
Product images are provided for reference and may not represent the exact model, configuration, or included components.

No Bots, Just Experts

Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.

Get Free Pre-Sales Support Buy Design Hours ($175/hr)
Description

STI KIT-SA505 Key Switch Mounting Bracket

Overview

The STI KIT-SA505 is a dedicated mounting bracket designed for SA5000 series key switch readers. This accessory enables secure installation of key switch credential readers in door control and access systems. Operating at 9VDC with HID credential support, the bracket provides mechanical stability for key switch-based authentication points in security installations.

Compatibility

This bracket is engineered specifically for the STI SA5000 series reader platform. Integrators deploying key switch readers in multi-door or distributed access environments will find this mounting solution essential for standardized, repeatable installations. The bracket accommodates HID credential systems and 9VDC powered readers.

Technical Specifications

  • Reader Type: Key Switch
  • Credential Type: HID
  • Operating Voltage: 9VDC
  • Compatibility: SA5000 Series
Expert Analysis
Specifications
Product Type: Lock/Strike
Credential Type: HID
Reader Type: Key Switch
Voltage: 9VDC
Type: Lock/Strike
Warranty: Manufacturer Warranty
Mount Type: Wall
Q&A
Reviews
Product Video
Have Questions?

STI KIT-SA505 Key Switch Mounting Bracket for SA5000 Series

$24.68
$23.99
Add to Cart
