STI Global ReSet Fire with Shield Fire Label - GR-RS-22-EN

STI GR-RS-22-EN Fire-Rated Reset Call Point Shield

Overview

The GR-RS-22-EN is a surface-mounted shield and fire label assembly designed to protect and identify STI Global ReSet Fire manual call points in fire-alarm and emergency-response installations. This shield eliminates the need for breakable glass — the call point simulates glass-break activation via mechanical reset, making it ideal for food processing plants, schools, shopping centers, and other facilities where glass hazards or high false-alarm rates present operational risk. The unit operates on 48VDC and includes a visible warning flag that displays when activated, paired with a reset mechanism that requires a key for reactivation. This approach cuts maintenance costs and injury risk in high-traffic or sensitive environments.

Compatibility

The GR-RS-22-EN shield is engineered to mount directly onto STI Global ReSet Fire call points and compatible manual fire-alarm stations within the STI fire-safety product family. The mounting plate drilling pattern accommodates single, double, and quad North American electrical boxes as well as European double and quad electrical enclosures — meaning the shield can integrate into existing electrical infrastructure without custom mounting. Verify compatibility with your specific call point model and electrical box configuration before ordering.

Installation Notes

Surface-mount installation requires standard electrical box preparation and secure fastening to the wall or enclosure surface using the provided drilling template. No breakable glass means no risk of accidental breakage during installation or maintenance. The reusable reset mechanism (key-operated) eliminates the need for replacement call-point cartridges after each activation — a significant cost and downtime reduction in environments prone to accidental alarms. The visible warning flag serves as both activation confirmation and visual deterrent, supporting both life safety and security objectives.

What's in the Box

• 1x Fire-rated shield enclosure
• 1x Fire label (preinstalled)
• 1x Mounting plate with universal drilling template
• Fasteners for electrical box attachment
