Middle Atlantic Single Gang Extron AAP FA - RFB119-AAP

Middle Atlantic RFB119-AAP Single Gang Extron AAP Adapter Plate

Overview

The Middle Atlantic RFB119-AAP is a single-gang adapter plate engineered for Middle Atlantic RFB-series rack furniture, giving integrators a clean, factory-finished way to mount one Extron AAP (Architectural Adapter Plate) module in a furniture opening. If you're building a presentation or collaboration space around Middle Atlantic furniture and need to drop in an Extron signal interface — HDMI, USB-C, VGA, audio — at the tabletop or lectern surface, the RFB119-AAP is the mechanical interface that makes it flush and professional. Without it, you're field-fabricating a solution that looks improvised and won't meet finish standards on a commercial install. The RFB119-AAP solves that in a single part with no cutting or custom work required.

Compatibility

This adapter plate is designed for the Middle Atlantic RFB-series furniture openings — specifically single-gang cutout positions within RFB enclosures and tops. It accepts the standard Extron AAP single-gang footprint, which covers Extron's full line of AAP signal interface modules: HDMI AAP, USB-C AAP, VGA AAP, DisplayPort AAP, audio AAP variants, and combination plates. Only Extron AAP-format modules fit this plate — do not attempt to use it with other manufacturers' single-gang inserts that do not conform to the Extron AAP mechanical standard. If your design calls for two AAP modules side by side, Middle Atlantic offers dual-gang variants in the same RFB furniture line; confirm the correct gang count before ordering. This plate does not include any Extron AAP module — Extron AAP signal modules are sourced separately.

Installation Notes

The RFB119-AAP drops into the standard RFB furniture single-gang opening and secures using the fasteners appropriate to the RFB enclosure. The Extron AAP module snaps or screws into the plate per Extron's own installation instructions for the specific AAP signal type selected. Confirm the RFB enclosure model supports single-gang inserts at the intended position before specifying this part — not all RFB configurations expose a single-gang opening at every location.
