Description

StarTech PM1115U2 USB Network Print Server

Overview

The StarTech PM1115U2 is a compact USB 2.0 print server designed to share a standard USB printer across an Ethernet network. This device bridges the gap between USB-only printers and network environments, allowing multiple users on a 10/100Mbps network to access a single printer without needing a dedicated host PC. It's ideal for small offices or workgroups that have a USB printer but require network accessibility, simplifying print management and reducing hardware costs. The PM1115U2 supports the LPR (Line Printer Remote) protocol for broad compatibility with Windows and other operating systems.

Compatibility

This print server is compatible with any USB 2.0 printer. It functions over standard 10Base-T and 100Base-Tx Ethernet networks. It supports Jumbo Frames up to 9K, which can improve network efficiency for large print jobs on compatible networks. The device operates using a standard 100-240V AC input, stepping down to 5V DC via the included power adapter.

Installation Notes

The device operates within a 0°C to 40°C (32°F to 104°F) temperature range and requires 10% to 90% non-condensing humidity. Its small form factor (2.1 x 2.1 x 0.9 inches) allows for discreet placement near the printer or network switch. The unit consumes a minimal 2 Watts of power.

What's in the Box

  • 1 - USB 2.0 Network Print Server
  • 1 - 5V DC Power Adapter
  • 1 - RJ45 Ethernet Cable
  • 1 - USB 2.0 Cable
  • 1 - Installation CD
  • 1 - Quick Start Guide
Specifications
Ethernet Speed: 10/100Mbps
USB Standard: USB 2.0
Network Protocol: LPR
Wired Network: 10Base-T, 100Base-Tx
Jumbo Frame Support: 9K max.
External Ports: 1 - RJ-45, 1 - USB 2.0 Type-A
Data Transfer Rate: 100 Mbps
Max Distance: 100m [328ft]
Power Consumption: 2 Watts
Operating Temperature: 0C to 40C (32F to 104F)
Storage Temperature: -10C to 70C (14F to 158F)
Humidity: 10% ~ 90% RH
Product Length: 2.1 in [53 mm]
Product Width: 2.1 in [5.4 cm]
Product Height: 0.9 in [2.3 cm]
Weight: 2.2 oz [62 g]
Input Voltage: 100 - 240 AC
Input Current: 0.25A
Output Voltage: 5 DC
Output Current: 1A
Warranty: 2 Years
Brand: StarTech
MPN: PM1115U2
Type: Power Supply
Connectivity: USB
Power: 240V AC
