Comnet SERVERSWITCHIQ - PRO 8 POE PORTS 130W QUAD CORE I5-4590S 4 TB - SSIQ8P-I5-4T

Comnet SSIQ8P-I5-4T 8-Port PoE Surveillance Switch with Integrated Storage

Overview

The Comnet SSIQ8P-I5-4T is a purpose-built network appliance that combines an 8-port PoE switch with an embedded quad-core processor and local storage, eliminating the need for a separate NVR in small-to-mid deployments. The model SSIQ8P-I5-4T delivers 130W of PoE power across 8 ports, runs a quad-core Intel i5-4590S processor, and includes 4TB of enterprise-grade storage — enough to handle continuous recording from multiple IP cameras without adding separate infrastructure.

Key Features

• 130W PoE Budget across 8 Ports: Supply power and network connectivity to up to 8 IP cameras over single ethernet cables. At 130W total, you can run high-power cameras (PoE+ devices drawing up to 30W each) or a mix of standard PoE and PoE+ without switch overload. This eliminates separate power supplies and simplifies site cabling.
• Quad-Core Intel i5-4590S Processor: Handles real-time video processing, edge analytics, and system management without outsourcing compute to a remote NVR. The 4-core architecture allows simultaneous stream processing from multiple cameras — meaningful when you need on-device motion detection, codec transcoding, or local analytics before pushing to cloud or central storage.
• 4TB Enterprise Storage Integrated: Built-in HDD provides 24/7 recording capacity for 8 cameras at 1080p baseline (exact retention depends on frame rate and codec). Enterprise-class drive lifespan and redundancy reduce failure risk compared to consumer storage. No external NVR box required for small branch offices or single-site surveillance.
• Compact All-in-One Design: Consolidates switch, processor, and storage into a single unit. Reduces rack footprint, simplifies power distribution (single feed instead of switch + NVR power supplies), and cuts cable runs in tight network closets or cabinet space.
• Gigabit Ethernet Connectivity: 8 Gigabit PoE ports deliver 1 Gbps throughput per camera port, preventing bandwidth bottlenecks when pulling full-resolution video streams locally. Sufficient headroom for simultaneous recording and remote streaming to a central VMS.
• Enterprise HDD with 24/7 Duty Cycle: The 4TB enterprise storage is rated for continuous operation — not consumer-grade desktop drives that fail under constant surveillance workloads. Ensures predictable uptime and longer replacement intervals.

Integration & Compatibility

The SSIQ8P-I5-4T is ONVIF-compliant, integrating with standard IP camera systems from major vendors. The embedded processor supports real-time recording and playback without dependency on external NVR software licensing. Local web interface allows configuration, playback, and remote access setup — no proprietary client software required. The quad-core i5 provides sufficient headroom for simultaneous PoE power delivery, storage I/O, and basic analytics without CPU saturation in typical 8-camera deployments.

Frequently Asked Questions

Q: Does the SSIQ8P-I5-4T support remote access and cloud backup?

A: The unit includes local web-based access for remote viewing over the network. Cloud integration and continuous backup depend on WAN bandwidth available at your site and whether you implement a secondary sync to cloud storage — the appliance itself stores video locally on its 4TB HDD.

Q: How many cameras can the 4TB storage support in a 24/7 scenario?

A: At 1080p 30 fps with H.264 compression, the 4TB drive typically holds 7–14 days of continuous recording for 8 cameras (exact duration depends on resolution, frame rate, and bitrate). Higher resolution or variable-frame-rate streams will reduce retention proportionally.

Q: Can the SSIQ8P-I5-4T replace both a PoE switch and a separate NVR?

A: Yes — that's the design intent. It provides PoE power delivery, network switching, video processing, and storage in one appliance. Best suited for deployments with 4–8 cameras and limited cabinet space or budget for separate hardware.

Q: What is the maximum PoE power per port?

A: The 130W total budget across 8 ports allows up to ~16W per port on average, with the ability to allocate more to individual ports if fewer cameras are in use. Confirm your camera's power draw (typically 6–25W for PoE/PoE+ devices) against the overall 130W limit when planning your camera mix.

Q: Does it support redundant storage or RAID?

A: The unit includes a single 4TB enterprise HDD. For mission-critical deployments requiring redundancy, consider a backup unit or implement secondary recording to a central NVR via network streaming.

Q: Is the SSIQ8P-I5-4T NDAA Section 889 compliant?

A: Compliance status is not documented in available evidence. Verify with the manufacturer or distributor if NDAA compliance is a requirement for your procurement.

Karl Wilson

The Comnet SSIQ8P-I5-4T addresses a real pain point for small branch deployments: you don't need (or can't justify) a full rack with separate PoE switch, NVR, and power distribution. This unit pulls that together — 130W PoE across 8 ports, quad-core i5-4590S processing, and 4TB enterprise storage in one chassis. It's the right tool if you're shipping to a remote office with one ethernet uplink and need 24/7 video recording without calling in a full systems install.

Technical Highlights:

• 130W PoE Budget: Sufficient for 8 cameras at typical power draws (12–18W per PoE device). If you're mixing high-power PoE+ cameras (25W+), count carefully — you can't exceed 130W total. Plan camera selection against the actual power envelope early.
• Quad-Core i5-4590S Processor: Handles simultaneous video streams and local analytics without external processing overhead. Real benefit for edge detection or codec conversion — you're not pushing every frame over WAN to a central server for analysis.
• 4TB Enterprise HDD: 24/7 duty cycle rated for continuous surveillance workloads. At 1080p 30 fps H.264, expect 7–14 days retention for 8 cameras before overwrite. Enterprise-class reliability beats consumer drives in uptime and MTBF (mean time between failure).

Deployment Considerations:

• Sizing matters: Calculate your camera power draw and confirm it stays under 130W total — no circuit breaker here, just a limit. If you add even one 40W camera later, you'll exceed budget and drop power to the weakest camera.
• Storage refresh: 4TB at 1080p gives you roughly 10 days' rolling buffer for 8 cameras. If you need 30-day retention, plan secondary NVR backup over the WAN or accept shorter local history.

Best fit: remote offices, warehouse surveillance, or branch locations where you need recording and PoE in one box and won't exceed 8 cameras. Not suitable for megapixel-heavy or 24+ camera sites — those demand dedicated NVR architecture.
