Comnet SERVERSWITCHIQ - PRO 8 POE PORTS 130W QUAD CORE I5-4590S 8 TB - SSIQ8P-I5-8T

Comnet SSIQ8P-I5-8T PoE Switch with Integrated Surveillance Storage

The Comnet SSIQ8P-I5-8T combines network switching, PoE power delivery, and onboard video storage in a single appliance—eliminating the need for separate NVR infrastructure in small-to-medium surveillance deployments. With 8 PoE ports delivering 130W total output, a quad-core i5-4590S processor, and 8TB of dedicated video storage, this unit handles endpoint power, data routing, and recording duties simultaneously. If your deployment spans 4–8 cameras and you want to simplify cabinet footprint and cabling, this integrated approach is worth evaluating.

Key Features

• 8 PoE Ports, 130W Total Output: Sufficient to power 4–6 typical surveillance cameras (13–25W each) simultaneously with headroom for growth. Each port negotiates power delivery independently, so mixed-draw devices (mix of high-power PTZ and low-power fixed cameras) coexist without port conflicts.
• Quad-Core i5-4590S Processor: Real CPU muscle means the switch doesn't just pass frames—it can perform light analytics, transcode streams, and manage multiple concurrent recording sessions without dropping packets or stuttering playback.
• 8TB Onboard HDD Storage: Purpose-built for continuous video recording. At typical H.264 bitrates (2–5 Mbps per camera for 1080p), this storage supports 24/7 recording of 4–8 simultaneous streams for 20–40 days before circular overwrite. No separate NVR rack space required.
• Solid State Boot Drive: Separate SSD for OS and application code ensures fast startup and responsive management interface—critical when you're troubleshooting live incidents and can't wait for mechanical disk spin-up.
• Integrated Management Interface: Built-in web UI and supporting software stack let you configure PoE per-port, monitor uplink bandwidth, set recording policies, and review video—all from one appliance. Reduces truck rolls for administrative changes.
• Gigabit Ethernet Connectivity: All ports run at 1 Gbps, delivering 1000 Mbps of backhaul bandwidth to your core network or NAS. Supports multiple simultaneous camera streams plus management traffic without saturation on typical surveillance bitrates.

Integration & Compatibility

The SSIQ8P-I5-8T integrates with standard IP cameras that support PoE (802.3af or 802.3at). Its onboard processor and storage mean it can function as a standalone recording appliance for small sites, or feed video upstream to a larger NVR infrastructure if you need centralized management across multiple locations. Ethernet uplink provides LAN and WAN connectivity for remote monitoring, configuration, and backup. Check your camera manufacturer's documentation to confirm ONVIF compliance and bitrate expectations at your desired resolution and frame rate—this shapes how many cameras you can record continuously on the 8TB budget.

Deployment Context

This appliance fits retail locations, small warehouses, office campuses, or remote sites where you want to avoid a separate rack-mount NVR but need reliable local recording. The combination of PoE switch and storage in one box also appeals to integrators managing inventory—fewer SKUs to stock, simpler installation training, and one power cable instead of two. For larger deployments (16+ cameras) or sites requiring redundant storage, step up to a dedicated NVR paired with a separate managed PoE switch.

Frequently Asked Questions

Q: What compression formats does the SSIQ8P-I5-8T support for recording?

A: Evidence does not specify compression support. Consult the product datasheet or contact the manufacturer for codec details (typically H.264, H.265, or both).

Q: Can I daisy-chain multiple SSIQ8P-I5-8T units for larger deployments?

A: The unit includes Gigabit Ethernet uplink for network connectivity. Multiple units can be networked together via standard Ethernet, though centralized management would depend on the management software capabilities. Verify interoperability with your VMS or management platform.

Q: What is the warranty on the SSIQ8P-I5-8T?

A: Warranty information is not provided in the product evidence. Contact the manufacturer or your reseller for warranty terms and support options.

Q: Does the SSIQ8P-I5-8T support remote access and cloud backup?

A: The unit includes network connectivity and a management interface, but cloud or remote backup capabilities depend on the specific management software included. Verify integration with your preferred monitoring or backup platform before purchase.

Q: How loud is the SSIQ8P-I5-8T in operation?

A: Noise specifications are not included in the available evidence. Contact the manufacturer for acoustic operating characteristics, particularly important if the unit will be installed in a temperature-controlled server closet within office or retail space.

Q: What is the power consumption and do I need a UPS?

A: Total power draw (switch, processor, drives, and PoE delivery) is not specified in available documentation. For a system this critical to surveillance continuity, UPS backup is strongly recommended. Consult the spec sheet for total wattage to size an appropriate backup power system.

Ted Perry

The SSIQ8P-I5-8T is a pragmatic piece of kit if you're tired of managing separate switch and NVR boxes in small surveillance projects. The quad-core i5-4590S processor actually matters here—it means the unit can handle real recording workloads and concurrent playback without the laggy, frustrated-engineer experience you get from underpowered appliances. The 8TB dedicated storage and separate SSD boot drive show that Comnet thought through the use case: fast responsiveness for config changes, reliable long-term video storage without competing I/O demands.

Technical Highlights:

• 130W PoE Budget Across 8 Ports: Typical 1080p IP camera draws 12–18W; a PTZ or turret might hit 25–30W. This power envelope covers a small multi-camera site without oversubscription. If you load all 8 ports with 18W cameras, you're at ~144W—slightly over budget—so verify your actual camera power specs before final design.
• Quad-Core i5-4590S with Dedicated SSD Boot Drive: Real CPU resources mean OS responsiveness, smooth playback scrubbing, and capability for light video analytics or transcode tasks. The SSD ensures you don't wait on mechanical disk seeks when accessing management functions during a live incident.
• 8TB HDD for 24/7 Recording: At 3 Mbps average per camera (aggressive compression or lower-res settings), you get roughly 30–40 days of retention on 4–6 simultaneous streams. Circular recording overwrites oldest data automatically. Plan for your retention policy upfront—if you need 90+ days, external NAS or cloud backup becomes necessary.

Deployment Considerations:

• The processor and storage are fixed—no modular upgrades later. If your deployment grows beyond 8 cameras or you need more than 8TB retention, this unit becomes a bottleneck. Plan for your actual camera count and bitrate budget before purchase.
• Power consumption (switch logic, processor, dual drives) is not published in available specs. If this appliance sits in an unmanaged closet or outdoor cabinet, verify thermal dissipation and ensure adequate ventilation. Rack-mount or wall-mount installation assumes you've accounted for ambient temperature and airflow.

The SSIQ8P-I5-8T is strongest for retail or small warehouse deployments where footprint matters and you want one appliance handling network switching, PoE distribution, and recording simultaneously. If your cameras are clustered in one location and you're not chasing multi-site federation, this approach beats two separate boxes and saves cable runs.
