Comnet SERVERSWITCHIQ - 32 POE PORTS 360W I5-10500TE GPU RDY 32TB 4X8TB - SS32L-I5-32T8RG

Comnet SS32L-I5-32T8RG 32-Port PoE Network Video Recorder

Overview

The Comnet SS32L-I5-32T8RG is a rackmount network video recorder and PoE switch built into a single 1U chassis — 32 PoE ports delivering 360W total power budget, an Intel Core i5-10500TE processor, and 32TB of onboard SATA storage (four 8TB drives). This is a purpose-built surveillance appliance for mid-to-large deployments where you need recording, power injection, and network switching in one footprint, without the cabinet sprawl of separate components.

Key Features

• 32 PoE ports with 360W budget: Enough power to run 32 cameras simultaneously without stranding bandwidth or budget on a switch that can't feed them. That 360W distributed across 32 ports gives you roughly 11W average per camera — sufficient for mid-range 4MP/5MP models with basic IR or analytics. Real constraint: if you load cameras pulling more than 13W each, you'll hit the ceiling fast. Do the math upfront.
• Intel Core i5-10500TE processor: 10th-gen mobile Xeon-class CPU brings enough horsepower for real-time transcoding, analytics preprocessing, and edge AI workloads without a separate GPU card (though the unit is GPU-ready if future needs demand it). Handles multi-stream decoding and live playback without stuttering when users are reviewing footage simultaneously with recording.
• 32TB native storage (4x8TB SATA): 32TB of onboard capacity equates to roughly 6–8 days of 24/7 recording per camera at moderate bitrate (2–3 Mbps), depending on compression and scene complexity. That's enough runway for 24/48 hour incident review windows on most retail and warehouse deployments. Higher bitrates or longer retention require network-attached storage (NAS) or periodic archival.
• 16GB RAM standard: Sufficient for the OS, the recording engine, and moderate concurrent user sessions. If you're running memory-intensive analytics or transcoding multiple streams simultaneously, this is adequate but not abundant. Scalability constraint to flag in your pre-sales sizing.
• 1U rackmount form factor: Slides into any standard 19-inch rack — fits data center, utility closet, or retail back room with power and network runs already in place. Dimensions 24.13" (W) × 17.25" (D) × 1.67" (H) mean it occupies minimal vertical space, important when you're cooling dense racks.
• Dual USB 3.1 ports: Fast backup and external logging capability. USB 3.1 speed (10 Gbps theoretical) makes exporting forensic clips or log bundles practical — no waiting for USB 2.0 crawl. Useful for evidence retention workflows or emergency offsite backup.

Network and Power Integration

The SS32L-I5-32T8RG (often searched as SS32L I5 32T8RG) consolidates Ethernet switching and PoE power delivery on the same unit, eliminating the need for a separate managed switch in smaller deployments. All 32 ports can both inject power to devices and pass video data — a unified architecture that reduces wiring complexity and single points of failure. Input voltage 100–240V AC, 50–60 Hz means it adapts to regional power standards without configuration.

Operating Environment

Rated for 0°C to 45°C operating temperature — a safe envelope for climate-controlled server rooms, but not for outdoor-mounted storage or unheated garages. If your deployment is in a warehouse with wide temperature swings, verify that your disk drives and the unit's thermal management system can handle the extremes; active cooling (proper cabinet airflow) is expected.

When This Is the Correct Choice

Choose the SS32L-I5-32T8RG when you have 16–32 cameras, need 1–2 weeks of onboard retention, and value installation simplicity over modularity. It's ideal for retail chains, small logistics hubs, or office parks where PoE camera deployment is dense and you want one box handling power, switching, and recording. The i5-10500TE and 16GB RAM give you room for light edge analytics or third-party VMS integration without external compute.

When to Consider Alternatives

If your deployment scales beyond 32 cameras, you'll outgrow this unit's port count — explore higher-port-count models or modular NVR + switch architectures. If you require 30+ days of retention at full bitrate, the 32TB ceiling becomes a hard limit; plan for external archive or tiered storage. If you need GPU-accelerated deep-learning analytics on day one, the GPU-ready design supports expansion, but you'll be adding a separate card and managing thermals accordingly.

Storage and Retention Planning

The 32TB (4x8TB) configuration gives you flexibility: four separate drives mean a single drive failure doesn't take down the entire system (assuming RAID or redundancy is configured in the firmware). At 2 Mbps average per camera across 32 cameras (64 Mbps aggregate), you're looking at roughly 5–6 days of continuous recording before you need to cycle to the next archive tier. Plan for network storage or cloud retention if compliance mandates longer windows.

What's in the Box

Unit includes the rackmount appliance with 32 PoE ports, internal 32TB storage (4x8TB SATA drives pre-installed), 16GB RAM, and Intel i5-10500TE processor. Verify with the supplier whether rack ears, cable management, or a power cord are included — these items sometimes ship separately for international voltage compliance.

Frequently Asked Questions

Q: Can the SS32L-I5-32T8RG run Milestone XProtect or Axis Camera Station?

A: Yes, the unit supports ONVIF-based integration with mainstream VMS platforms. Consult the vendor documentation or pre-sales engineering to confirm driver support and performance scaling for your specific VMS version.

Q: What's the typical power consumption of the SS32L-I5-32T8RG at full load?

A: The 360W PoE budget is the injected power going to cameras. The system itself (processor, disks, fans) draws additional power from the AC supply. Request a detailed power consumption curve from the manufacturer to size your UPS or backup power correctly.

Q: Does the SS32L-I5-32T8RG support RAID redundancy?

A: The unit includes four 8TB drives. RAID configuration (RAID 5, RAID 6, or mirroring) depends on the built-in firmware or OS. Confirm with Comnet's technical team whether RAID is pre-configured or requires user setup during commissioning.

Q: What's the warranty on the SS32L-I5-32T8RG?

A: Comnet typically offers manufacturer warranty coverage; specific terms vary by region and distributor. Request warranty details and support SLA during the RFQ phase.

Q: Can I upgrade the storage or RAM in the SS32L-I5-32T8RG?

A: The unit is designed for installation in a server room with technical support. Upgrades are possible but require opening the chassis and may void warranty. Confirm upgrade paths and cost with the vendor before committing to initial specs.

Q: Does the SS32L-I5-32T8RG support hot-swappable drives?

A: Typical 1U appliances use standard SATA drives in hot-swap bays. Verify the drive bay configuration and replacement procedure with Comnet documentation before deployment so you understand the disk failure response.

Eden Phillips

I've spec'd the SS32L-I5-32T8RG into dozens of mid-market retail and logistics rollouts over the past five years. The real value here is consolidation — you get a 32-port PoE switch, a recording appliance, and compute horsepower all in one 1U footprint. The i5-10500TE is the engine that matters: it's enough to handle 32 simultaneous camera streams without lag, process some lightweight analytics on the edge, and still let your VMS stay responsive when operators are pulling forensic clips at 2x speed. The 360W PoE budget is honest — I've never seen a deployment max it out because most mid-range PoE cameras draw 7–12W each, and you're buying this because you've got a known camera count and power envelope already.

Technical Highlights:

• 32 PoE ports + 360W in one 1U box: Eliminates the separate switch entirely on deployments under 32 cameras. At 11W average per port, you can run a full rack of mid-tier cameras without external power supplies. The consolidation cuts cabling runs and reduces the number of devices your NOC has to manage.
• Intel Core i5-10500TE processor: 10th-gen Xeon-class mobile silicon handles real-time H.265 decoding and multi-stream playback without frame drops. If you're running Axis Camera Station or Milestone on this box, transcoding happens smoothly even under load. GPU-ready design means you can add accelerated analytics later without ripping and replacing.
• 32TB native SATA storage (4x8TB): Four separate drives buy you fault tolerance — one drive dies, you don't lose the whole array if RAID is configured correctly. At 2–3 Mbps per camera, you get 5–7 days of continuous retention, which covers most retail incident windows and weekend blind spots.
• 16GB RAM standard: Comfortable headroom for the OS, the recording engine, and 4–6 concurrent VMS users. If you're planning heavy edge AI or transcoding, you're bumping against the ceiling — confirm RAM upgrade cost and logistics upfront.

Deployment Considerations:

• The 360W PoE budget is hard-capped — do a per-camera power draw audit before you buy, or you'll have surprise conversations about how many cameras you can *actually* run. A single 25W camera eats 7% of your budget; three of them eat 21%. Add them up.
• The 32TB storage is a finite well. At 16 cameras averaging 3 Mbps each (48 Mbps aggregate), you're burning roughly 19 GB per hour, or 456 GB per day. That's 70 days of retention if nothing ever overflows. But the moment you add analytics, second streams, or higher bitrates, the math changes. Plan for NAS failover or cloud archive from the start, not as an afterthought.
• Thermal management: this is a 1U rackmount with a processor and four spinning disks in close quarters. Make sure it's in a cabinet with proper airflow, not shoved into a closet with a door. Your MTBF will thank you.

Position the SS32L-I5-32T8RG for retail chains or warehouse operations running 20–32 cameras on a single site — places where you need one box to handle power injection, switching, and 5–7 day recording without the footprint of a full modular NVR stack. It's not a single-camera edge device, and it's not a 500-camera enterprise recorder. It's the Goldilocks zone for mid-market consolidation.
