Comnet SERVERSWITCHIQ - 32 POE PORTS 360W I5-10500TE GPU RDY 72TB 4X18TB - SS32L-I5-72T18G

Comnet SS32L-I5-72T18G Integrated NVR and PoE Switch

Overview

The Comnet SS32L-I5-72T18G is a hybrid network video recorder and managed PoE switch in a single 1U chassis, purpose-built for mid-to-large surveillance deployments where you need local recording capacity and direct PoE power delivery to 32 cameras without a separate switch. The combination of an Intel i5-10500TE processor, 72TB native storage (four 18TB drives), 16GB RAM, and 32 PoE ports outputting 360W makes this a pragmatic choice for integrators who want to simplify rack architecture and reduce both cabling runs and power supply complexity.

This unit is not a general-purpose edge appliance—it's purpose-built for the surveillance integrator who needs to record from up to 32 networked cameras, power them all from one device, and manage the entire system from a centralized location. The SS32L-I5-72T18G (often searched as SS32L I5 72T18G) sits in the sweet spot between dedicated NVRs that lack PoE and managed switches that lack storage.

Key Features

• 32 PoE Ports with 360W Budget: Delivers PoE to 32 cameras simultaneously—enough for a typical 2–3 building campus or a large warehouse. 360W total means you can run high-power devices like PTZ cameras or thermal units alongside standard fixed cameras on the same power backbone, without needing external PoE injectors or extra PSUs.
• 72TB Storage (4x18TB RAID-Ready): Four 18TB hard drives provide approximately 30–40 days of 24/7 continuous recording from 32 HD cameras (exact retention depends on resolution and codec). The multi-drive architecture supports RAID configuration, protecting against single-drive failure without losing your archive.
• Intel i5-10500TE Processor: Six-core desktop-class CPU handles real-time encoding, transcoding for remote viewing, and analytics processing without stuttering or frame drops. This is not an ARM SoC—you get x86 performance for complex VMS tasks, third-party plugins, and GPU-accelerated inference if needed.
• 16GB Standard RAM: Sufficient for smooth multi-stream playback, concurrent remote viewing sessions, and running edge analytics or AI plugins without memory pressure. Eliminates the bottleneck of undersized RAM that plagues entry-level NVRs.
• 1U Rack Enclosure (24.13" × 17.25" × 1.67"): Fits standard 19-inch racks, reducing floor space in server rooms or network closets. The shallow depth (1.67 inches) leaves room for patch panels and redundant cabling behind the unit, a practical detail often overlooked in compact designs.
• Dual USB 3.1 Ports: Fast USB for exporting video segments, backing up configuration, or connecting external diagnostic tools without blocking network bandwidth or tying up the system.

Integration & Compatibility

The SS32L-I5-72T18G functions as both a standard ONVIF-compliant NVR and a managed network switch. IP cameras connect directly to the PoE ports; the unit records their streams to local storage and provides network switching between those cameras and your management network. Redundant Ethernet uplinks allow connection to your corporate LAN or multiple monitoring stations. The Windows or Linux-based NVR software integrates with common VMS platforms via ONVIF, RTSP, or vendor-specific APIs, depending on your licensing and deployment model. No additional PoE injectors, separate switches, or external power distribution units are needed—a major simplification in cabinet density and UPS runtime calculations.

Environmental and Operating Specifications

The unit operates across 0°C to 45°C (32°F to 113°F), suitable for indoor rack deployment in climate-controlled data centers or server rooms. Universal input voltage (100–240V AC, 50–60Hz) accommodates global installations. The 1U form factor and sealed design protect against dust and minor environmental stress common in commercial closets, though this is not a ruggedized field appliance—keep it in a controlled environment.

What's in the Box

Verify with the supplier for exact package contents, as Comnet sometimes ships core units and storage separately depending on the order configuration.

Frequently Asked Questions

Q: Does the SS32L-I5-72T18G support RAID configuration on the four 18TB drives?

A: Yes. The unit supports RAID 0, 1, 5, or 6 depending on your redundancy requirements. RAID 5 or 6 is recommended for production surveillance to protect against drive failure without losing recorded video.

Q: Can I expand storage beyond the 72TB baseline?

A: The SS32L-I5-72T18G has four internal 3.5-inch drive bays. Expansion beyond 72TB requires external networked storage (NAS) or a second recorder. Check with Comnet on hot-swap bay support.

Q: What is the maximum number of concurrent viewing sessions the SS32L-I5-72T18G can handle?

A: The i5-10500TE and 16GB RAM support 5–10 simultaneous remote users depending on bitrate and resolution. High-definition multi-stream playback may require optimization of codec settings or dedicated bandwidth allocation.

Q: Is the SS32L-I5-72T18G NDAA Section 889 compliant?

A: Comnet does not explicitly list NDAA compliance for this model. If federal or NDAA-restricted procurement is required, contact the vendor for official certification status.

Q: What PoE standard does the SS32L-I5-72T18G support?

A: The 32 ports deliver PoE budget across 802.3af/at/bt modes. With 360W total, the unit can power a mix of standard (13W), PoE+ (30W), and some PoE++ devices in parallel, though not all 32 ports at maximum wattage simultaneously.

Q: Does the unit include VMS software or do I need to license separately?

A: The SS32L-I5-72T18G is a bare NVR appliance. VMS software (Milestone, Genetec, Comnet's own platform, or open-source alternatives) must be installed or licensed separately.

James Everett

The SS32L-I5-72T18G consolidates two traditionally separate devices—a managed PoE switch and an NVR—into a single 1U form factor. That architectural choice matters. You eliminate at least one extra appliance from your rack, simplify cabling, and reduce the power budget UPS calculation by distributing recording and switching into one PSU. The i5-10500TE is a solid choice for handling real-time multi-stream recording and transcoding without frame loss, and 72TB of RAID-capable storage gets you roughly 30–40 days of continuous 24/7 footage from 32 HD sources depending on codec and resolution.

Technical Highlights:

• 360W PoE Output Across 32 Ports: Enough to power a mix of standard PoE cameras (13W), PoE+ thermal units (30W), and PTZ domes (50W+) without external injectors or auxiliary PSUs. That's meaningful cost and space savings on a multi-building campus where you might otherwise need one PoE switch per building plus a centralized recording server.
• Intel i5-10500TE with 16GB RAM: Six-core processor handles H.264/H.265 encoding, concurrent remote playback transcoding, and basic edge analytics without stuttering. 16GB RAM eliminates memory throttling on multi-user playback—a gotcha on cheaper NVRs that ship with 4–8GB.
• 72TB via Four 18TB Drives in RAID: RAID 5 or 6 protects you against unplanned drive failure without data loss. At typical bitrates (4–8 Mbps per camera), that's 30–40 days of 24/7 storage—enough for most corporate compliance windows and root-cause video forensics.
• 1U Shallow Chassis (1.67") with Dual USB 3.1: Fits standard racks without special cabinets. USB 3.1 lets you export incident video or back up configuration to external drives without clogging network bandwidth during active recording.

Deployment Considerations:

• The 360W PoE budget is the ceiling—you cannot simultaneously max out all 32 ports at 11W each. Plan your camera mix carefully; PTZ units and thermal cameras burn 40–60W each, so a deployment with 10 PTZ domes and 22 standard fixed cameras will saturate the budget. Audit your actual power draw per camera before committing.
• The unit requires climate-controlled rack space (0–45°C operating range). Do not rely on it for outdoor or untempered closet environments. Thermal stress reduces drive lifespan and processor reliability.
• VMS software is not included. Budget for licensing Milestone, Genetec, or Comnet's platform, which can add $2k–10k depending on camera count and feature tier. The bare appliance is the hardware—your integration complexity lives in the software layer.

The SS32L-I5-72T18G is well-suited for integrators deploying 20–32 networked IP cameras in a single-site or multi-building scenario where you want centralized storage, unified PoE, and enough CPU horsepower to handle remote viewing and basic analytics without a separate switch and recorder pair. It's a rack-efficient consolidation play, not a feature-rich analytics engine. If your client needs advanced deep-learning analytics or multi-site federation, plan for external GPU acceleration or a separate analytics server downstream.
