APC by Schneider Electric AP8862 Rack-Mount Power Distribution Unit

Overview

The AP8862 is a high-density, rack-mountable power distribution unit from APC by Schneider Electric designed for 3-phase 208V data center and server room installations where you need to distribute substantial AC power across a large number of endpoints from a single feed. It accepts a 20A 3-phase input via a NEMA L21-20P plug on a 6-foot (1.83m) cord and distributes that load across 36 NEMA 5-20R receptacles — enough to power a full rack of 1U/2U servers, network switches, or network video recorders without daisy-chaining strips or splitting feeds across multiple PDUs. The regulatory derated current ceiling is 16A, keeping you within the 80% NEC continuous-load rule automatically. At 70.5 inches (179.1cm), this unit is sized for a standard 42U tall rack and mounts vertically in the rear channel.

Compatibility

Pairs directly with any rack infrastructure accepting a vertically-mounted zero-U PDU at 179.1cm — including APC NetShelter SX, SV, and CX series enclosures. The NEMA L21-20P input requires a matching 208V 3-phase circuit from a PDU transfer switch, 3-phase UPS output, or panel with an L21-20 receptacle; confirm your upstream device provides L21-20 output before ordering. The 36 NEMA 5-20R receptacles support standard 15A and 20A single-phase loads — compatible with the majority of 1U rack equipment drawing under 20A per outlet. Works with rack-mount UPS systems that output 208V 3-phase, such as APC Symmetra and Galaxy series units with matching output connectors. Not suited for single-phase 120V-input panels or IEC-outlet equipment without adapters.

Installation Notes

Operating range is -5°C to 45°C with 5–95% relative humidity (non-condensing) up to 3,000 meters elevation — standard data center envelope. Verify that the upstream 3-phase circuit breaker is rated for 20A per pole and that the panel branch circuit matches the L21-20P plug configuration before connecting. The 16A derated maximum total draw governs load planning: size your connected equipment to stay at or below 16A aggregate to avoid nuisance tripping under continuous operation. No tools required for outlet connections; standard rack-mounting hardware for zero-U vertical rail attachment should be confirmed against your specific enclosure model.
