Vertiv VP5N60A9 Switched Rack PDU
Overview
The Vertiv VP5N60A9 is a switched rack power distribution unit (PDU) designed for high-density data center environments. It provides 60A of 208V Delta power with a total capacity of 17.2KW, distributed across 24 vertical outlets. This unit offers granular control and monitoring at the individual outlet level, allowing for remote power cycling of connected equipment to manage power consumption and troubleshoot issues without physical access. Its vertical form factor is optimized for standard server rack installations, maximizing power density within the rack.
Compatibility
This PDU is designed for integration into standard 19-inch server racks. It is compatible with any server, network, or storage equipment requiring 208V Delta power input up to 60A. The unit-level monitoring capabilities integrate with data center infrastructure management (DCIM) software platforms that support SNMP or other standard network protocols for remote data collection and analysis.
Installation Notes
Requires a 208V Delta electrical service connection. Installation must be performed by qualified personnel familiar with high-voltage electrical systems and data center PDU mounting procedures. Ensure adequate clearance for airflow around the PDU and connected equipment within the rack. The vertical mounting orientation requires sufficient vertical space within the rack cabinet.
What's in the Box
- 1x Vertiv VP5N60A9 Switched Rack PDU
- 1x Power Cord (attached)
- 1x Mounting Hardware Kit
