Vertiv VP4N60A2 Monitored 3-Phase Vertical PDU — 60A / 208V / 17.2kW
Overview
The Vertiv VP4N60A2 is a unit-level monitored, three-phase vertical PDU rated at 60A / 208V Delta, delivering up to 17.2kW of power distribution to high-density data center and colocation racks. Designed for 0U vertical installation, it keeps all 24 outlets accessible without consuming a single rack unit — a practical advantage in fully populated cabinets where horizontal real estate is already committed. The VP4N60A2 connects via a 3-meter IEC 60309 input cord and provides real-time current, voltage, and power monitoring through a built-in LED display and full network management stack, giving operations teams the visibility they need without deploying additional metering hardware.
If you're running dense compute, GPU clusters, or high-draw networking gear in a colo environment where per-rack capacity billing and power cap compliance matter, unit-level monitoring at the PDU provides an accurate, always-on view of what's actually being drawn — down to the outlet type, so you can balance C13 and C19 loads deliberately rather than by guesswork. Browse the full Vertiv power distribution catalog for complementary models across amperage and phase configurations.
Key Features
- 60A Three-Phase Input at 208V Delta: At 17.2kW available load capacity, the VP4N60A2 handles the heaviest per-rack loads common in GPU compute and hyperconverged deployments — where a single rack can pull 15–20kW. Sizing this correctly at the PDU level means you're not chasing a blown breaker during peak workloads.
- 24 Locking Outlets — C13 and C19 Mix: Locking IEC connectors prevent inadvertent disconnection in environments with cable congestion or vibration. The mix of C13 (standard 1U server draws) and C19 (high-amperage devices up to 16A per outlet) gives you flexibility to power both server-tier and power-supply-tier equipment on the same PDU without adapters.
- Vertical 0U Mounting: Installing the VP4N60A2 vertically along the rack rail leaves all 42U of rack space available for revenue-generating hardware. In high-density colo racks where every U costs money, this form factor is not a cosmetic choice — it's a capacity decision.
- Unit-Level Current, Voltage, and Power Monitoring: Real-time visibility into the full PDU load (not per-outlet) lets you track capacity utilization, catch load imbalances across phases, and feed data to your DCIM or BMS platform. The onboard LED display provides at-a-glance current readings without a management session.
- Comprehensive Network Protocol Support: SNMP v1/v2c/v3, HTTPS, SSH, Modbus TCP, LDAP, RADIUS, TACACS+, Syslog, and NTP are all supported out of the box. This means the VP4N60A2 can integrate into enterprise SNMP-based monitoring platforms (PRTG, Nagios, SolarWinds, Zabbix) or DCIM tools without a custom driver or middleware layer. SNMP v3 with auth/priv encryption satisfies most enterprise security policies; TACACS+ and RADIUS enable centralized credential management rather than per-device local accounts.
- IPv4 and IPv6 Dual-Stack: Full IPv6 support future-proofs the management interface for environments already transitioning away from IPv4 addressing — particularly relevant in carrier and service provider deployments.
- 3-Meter Input Cable (IEC 60309): The 3m cord provides enough reach to route cleanly to an overhead or underfloor whip without sharp bends or extension cables. IEC 60309 (industrial-grade) connectors at the input handle the connector seating forces that repeated plug/unplug cycles impose in a live data center.
- Onboard Serial, Ethernet, and USB Ports: The single RJ-45 Ethernet port connects to your OOB management network. The serial port supports console access for initial configuration or fallback management if the network path drops. The USB port enables local config import/export or firmware updates without a network path.
- 50/60 Hz Compatibility: The VP4N60A2 accepts 50 or 60 Hz input, making it deployable in both North American and European-standard three-phase environments without hardware changes — useful for organizations managing multi-region data center infrastructure under a single procurement process.
Integration and Compatibility
The VP4N60A2 fits naturally into three-phase PDU deployments alongside DCIM platforms that poll via SNMP v3 or Modbus TCP. Organizations running Vertiv's Trellis DCIM or third-party platforms (nlyte, Sunbird, Raritan Power IQ) will find the SNMP MIB and Modbus register map follow Vertiv's standard Geist-lineage architecture. The LDAP, RADIUS, and TACACS+ support means you can provision user authentication through Active Directory or a centralized AAA server — no local user management sprawl across dozens of PDUs. For network infrastructure racks with PoE switches and high-density patch panels, the C13/C19 outlet mix handles both switch and server-class power draws.
Facilities teams integrating with a UPS infrastructure upstream of this PDU should confirm the upstream circuit is provisioned for a 60A three-phase feed — the IEC 60309 input requires a matching receptacle, typically installed at the rack whip during facility fit-out. Review the data center power planning guide if you're sizing circuits for a new cage or pod build-out.
Frequently Asked Questions
Q: What input plug type does the VP4N60A2 require at the facility level?
A: The VP4N60A2 uses an IEC 60309 input connector on a 3-meter cord. Your facility circuit or overhead whip must terminate in a matching IEC 60309 receptacle rated for 60A three-phase. Verify this with your facilities or colocation provider before ordering.
Q: Does the VP4N60A2 provide per-outlet switching or monitoring, or only unit-level?
A: The VP4N60A2 is a unit-level monitored PDU — it reports current, voltage, and power at the PDU level, not per individual outlet. If you need per-outlet switching or per-outlet metering, you'll need to evaluate a different model in Vertiv's Geist PDU line with outlet-level intelligence.
Q: Which SNMP versions does the VP4N60A2 support?
A: The VP4N60A2 supports SNMP v1, v2c, and v3. SNMP v3 with authentication and privacy encryption is recommended for enterprise deployments where management traffic crosses shared network segments.
Q: Can the VP4N60A2 be managed with centralized authentication — Active Directory, RADIUS, or TACACS+?
A: Yes. The PDU supports LDAP, RADIUS, and TACACS+ for centralized user authentication and authorization. This allows you to manage PDU access through your existing AAA infrastructure rather than maintaining local credentials on each unit.
Q: What is the total outlet count and what outlet types are provided?
A: The VP4N60A2 provides 24 total AC outlets — a mix of IEC C13 and IEC C19 locking connectors. C13 outlets handle standard server and 1U equipment power supplies; C19 handles higher-draw devices up to 16A. All outlets use locking connectors to prevent accidental disconnection.
Q: Is the VP4N60A2 compatible with both 50 Hz and 60 Hz power environments?
A: Yes, the PDU accepts 50/60 Hz input at 200–240V, making it suitable for deployment in both North American (60 Hz) and international (50 Hz) three-phase data center environments.
The VP4N60A2 sits at a specific intersection I pay attention to: 60A three-phase at 208V Delta in a 0U vertical form factor with full SNMP v3 and TACACS+ support. That combination tells me this unit was designed for enterprise colo and carrier-grade deployments where both power density and security policy compliance are non-negotiable on the same rack.
Technical Highlights:
- 17.2kW at 60A / 208V Three-Phase: This is genuine high-density headroom. A rack pulling 15kW from GPU compute or hyperconverged nodes still leaves margin before you hit the 60A breaker — meaning you can grow into the rack without a PDU swap.
- SNMP v3 + TACACS+ + RADIUS: Most monitored PDUs in this class support SNMP v2c and stop there. Full SNMP v3 with auth/priv plus AAA protocol support (RADIUS and TACACS+) means this PDU can satisfy enterprise security audits that require encrypted management and centralized credential control.
- Modbus TCP: Building management system integrations that speak Modbus TCP can pull power data directly from the VP4N60A2 without an SNMP-to-Modbus translator layer — a meaningful simplification in facilities with legacy BMS infrastructure.
Deployment Considerations:
- The IEC 60309 input requires a provisioned facility receptacle — confirm with your colo or facilities team that the overhead or underfloor whip terminates in the correct 60A three-phase IEC 60309 socket before the equipment arrives on site. Mismatched connectors at 60A are not a field-improvise situation.
- Unit-level monitoring means you're seeing total PDU load, not individual outlet draw. If your operations team needs per-outlet current data for chargeback, capacity planning at the device level, or remote outlet switching, this model does not provide that — step up to an outlet-monitored or outlet-switched variant in the Vertiv lineup.
For high-density colo builds where a customer or tenant needs a documented power usage report by rack, the VP4N60A2 with SNMP v3 polling into a DCIM platform gives operations the unit-level data trail without the cost of a fully switched PDU — the right tradeoff when outlet-level control isn't required but auditability is.
