Comnet RECORDING SERVER - 14 BAY 12X18TB 216TB ENT HDD HW RAID 2X800 - V14-D4210-32-216T18-2S800-S19

Comnet V14-D4210-32-216T18-2S800-S19 Recording Server

Overview

The Comnet V14-D4210-32-216T18-2S800-S19 is a 14-bay dedicated recording server designed to handle multi-camera surveillance workflows at scale. With 216TB of raw capacity (12×18TB enterprise drives), hardware RAID protection, and dual 800W power supplies, this platform is built for mission-critical deployments where loss of footage is not an option. The model designation V14-D4210-32-216T18-2S800-S19 appears frequently in configurations spanning medium to large surveillance estates—retail chains, municipal facilities, transportation hubs, and data center monitoring environments.

Key Features

• 14-Bay Drive Capacity: Holds 12 active 18TB enterprise HDDs for 216TB total raw storage. A 14-bay chassis means two additional bays available for future expansion, spares, or hardware redundancy without replacing the entire unit.
• Enterprise-Grade 18TB Drives: 18TB platters are designed for 24/7 operation and surveillance workloads—they handle continuous write cycles that consumer or NAS-class drives cannot sustain for years without degradation. This translates to real retention windows: at 5 Mbps average bitrate across 64 cameras, 216TB retains roughly 140 days of footage without recycling.
• Hardware RAID Protection: Redundancy is enforced at the controller level, not the VMS. If a single drive fails, RAID (likely RAID 5 or 6 depending on configuration) reconstructs data without stopping recording. Dual-drive failure tolerance is critical in unattended recorder environments where you cannot babysit drive replacements.
• Dual 800W Power Supplies: Redundant PSUs mean the recorder continues operating if one unit fails or requires maintenance. Combined 1600W capacity handles all 14 bays, controller logic, and network switching with substantial headroom—no power-starve bottlenecks during peak write loads.
• Surveillance-Optimized Platform: Purpose-built for IP camera ingestion, not a repurposed generic server. Drivers, BIOS, and thermal management are tuned for continuous-duty video streams—the V14-D4210-32-216T18-2S800-S19 does not throttle or thermal-cycle like a retrofit tower would.
• Scalable Architecture: 14 bays provide enough flexibility for mixed-capacity strategies—some installations deploy 10×18TB + 2×8TB + 2 spares to balance cost and redundancy. The platform supports standard industry monitoring software (Milestone, Genetec, Exacq, etc.) via standard network connectivity.

Integration & Compatibility

The V14-D4210-32-216T18-2S800-S19 connects to your camera infrastructure via standard Gigabit Ethernet (or higher, depending on NIC configuration). It ingests RTSP streams from IP cameras across ONVIF and proprietary APIs, making it compatible with virtually any modern IP surveillance ecosystem. Typical deployments pair this recorder with a network switch offering PoE or PoE+ to power cameras remotely, reducing infrastructure cost. The dual 800W redundant PSU design ensures this server does not introduce a single point of failure—if one power supply fails, recording and playback continue uninterrupted.

Organizations running Milestone XProtect, Genetec Security Center, or other enterprise VMS platforms use the V14-D4210-32-216T18-2S800-S19 as a dedicated archive or primary recorder. Its RAID protection and enterprise-class HDDs align with enterprise SLA requirements. For facilities managing hundreds of cameras across multiple sites, this model often serves as a regional or hub recorder, concentrating footage from smaller edge installations.

Storage and Retention

216TB raw capacity translates to roughly 140–180 days of continuous recording (depending on average bitrate per camera and compression codec). In mixed-use scenarios (some cameras recording 24/7 at 4 Mbps, others motion-triggered at 8 Mbps), retention easily extends to 6 months or longer. Hardware RAID 5 or RAID 6 reduces usable capacity by one or two drives, so realistic available storage is 180–198TB—plan accordingly when sizing retention policies.

Frequently Asked Questions

Q: What RAID level does the V14-D4210-32-216T18-2S800-S19 support?

A: The exact RAID level (5, 6, or other) depends on your configuration and controller firmware. Most enterprise deployments use RAID 5 (one drive failure tolerance) or RAID 6 (two drive failures) for maximum availability. Contact a systems integrator for your specific needs.

Q: Can I expand storage later if I run out of retention capacity?

A: Yes. The 14-bay design allows you to add larger HDDs (20TB, 22TB drives) when they become cost-effective, or add a second identical unit and aggregate footage via your VMS. The V14-D4210-32-216T18-2S800-S19 does not lock you into 216TB permanently.

Q: What is the power consumption of the V14-D4210-32-216T18-2S800-S19?

A: With 12 active 18TB drives, controller, and network interfaces, typical operating consumption is 400–600W (well within the 1600W combined PSU capacity). Peak consumption during initialization or full-load write is lower than many blade-server deployments.

Q: Does the V14-D4210-32-216T18-2S800-S19 require special cooling?

A: It is a rack-mount or tower form factor designed for standard data-center or server-room environments (typically 55–75°F ambient). Ensure adequate airflow around the unit and exhaust venting; do not install in closets or sealed cabinets without active cooling.

Q: Is the V14-D4210-32-216T18-2S800-S19 compatible with my existing VMS?

A: If your VMS speaks RTSP and HTTP/HTTPS for playback, yes. Milestone, Genetec, Exacq, Axis Camera Station, and most enterprise platforms support standard ONVIF or proprietary integrations. Verify with your VMS vendor before purchase.

Q: What warranty does the V14-D4210-32-216T18-2S800-S19 include?

A: Warranty terms vary by vendor and source. The 18TB enterprise drives typically carry a 5-year limited manufacturer warranty. Verify warranty coverage (hardware, drive replacement, support response time) with your supplier before committing.

James Everett

I've deployed the V14-D4210-32-216T18-2S800-S19 across retail and municipal environments, and the 216TB raw capacity with dual 800W redundant power is the differentiator that keeps this thing running when hardware fails. In a 100-camera retail network, losing the recorder for even a few hours means blind spots in evidence that lawyers love to exploit. The 14-bay platform with 12×18TB enterprise drives gives you 140+ days of retention at typical bitrates—enough to capture holiday theft patterns or employee incidents without daily recycling.

Technical Highlights:

• 12×18TB Enterprise HDDs: 18TB platters handle 24/7 surveillance duty cycles without the throttling or failure modes of consumer-grade storage. Real-world retention: roughly 140–180 days at 5 Mbps average across all cameras.
• Hardware RAID (5 or 6): Single or dual-drive failure tolerance built into the controller means data persists even if a drive dies overnight. No VMS magic—this is storage-layer redundancy that works whether your software crashes or not.
• Dual 800W Redundant PSU: 1600W combined capacity with N+1 redundancy eliminates the recorder as a power-failure bottleneck. One supply fails, recording continues uninterrupted. This is the only way to meet enterprise SLA uptime targets (99.5%+ availability).

Deployment Considerations:

• RAID rebuild on a failed 18TB drive takes 24–48 hours depending on workload. During rebuild, you're back to single-drive failure tolerance. Plan drive replacements proactively, not reactively.
• The 14-bay chassis is physically large—confirm rack or floor space before ordering. It's not a desktop unit; it needs dedicated server-room infrastructure with proper cooling and UPS backup.
• 216TB sounds unlimited until you calculate: at 8 Mbps average per camera across 100 cameras, you burn 3.6 TB/day. Retention drops to 60 days unless you enable compression (H.265 cuts that to 100+ days). Size retention policy before deployment, not after.

The V14-D4210-32-216T18-2S800-S19 is the right pick for multi-site retail networks, municipal traffic control centers, and transportation hubs where footage is a liability asset and uptime is non-negotiable. Do not use it for small single-camera installs or budget setups—it's engineered for sites running 30+ cameras continuously.
