Ip Rating:
IP65
Mount Type:
Wall
Operating System:
DPSecureProfileverified Documentation
Color:
blackNCSS9000-N
Connectivity:
Cablerequirements
warranty:
5 Year(s)
weight:
0.26
width:
4.76
height:
1.89
depth:
1.06
Brand:
Axis
MPN:
03423-001
Type:
Expansion Module
Reader Protocol:
OSDP
Credential Technologies:
MIFARE Classic, MIFARE DESFire EV1, MIFARE DESFire EV2, MIFARE Plus
DC Input Voltage:
12-12 V
Safety Approvals:
CAN/CSA C22.2 No. 62368-1 ed.3, IEC/EN 62368-1 ed.3, UL 294, UL 62368-1 ed.3
Product Label Markings:
CE, FCC, ICES, UL, WEEE
Operating Temperature:
-40 to 65 °C
Outdoor Ready:
Yes
Reader Technology:
13.56 MHz ISO14443-A: MIFARE Classic , MIFARE Plus , MIFARE DESFire EV1, EV2, and EV3
Network Protocols:
Open supervised device protocol (OSDP) OSDP Secure Profile verified Multi-drop
Alarm Status Indication:
RGB LED for user feedback, buzzer
EMC:
CISPR 32 Class B, EN 61000-6-1, EN 61000-6-3, FCC Part 15 Subpart B Class B, RCM AS/NZS CISPR 32 Class B
Environment:
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK07
Wireless:
EN 62311, EN 300330, EN 301489-1, EN 301489-3, FCC Part 15 Subpart C, RSS-102, RSS-210
Cybersecurity:
EN 18031-1
Edge Security Software:
Signed device software
Edge Security Hardware:
Secure keystore: secure element (CC EAL 6+, FIPS 140-3 Level 3) Secure boot
Documentation:
Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/ cybersecurity/resources To read more about Axis cybersecurity support, go to axis.com/cybers
Casing:
IP65 and IK07–rated plastic casing Hard-coated scratch- and impact-resistant front
Mounting:
Suitable for mullion-mount door installations or any flat surface mounting
Power Input:
12 V DC
Current Consumption:
Typical 71 mA @12 V, max 114 mA @ 12V 13.56 MHz maximum RF transmit power = -40.3dBm (ERP)
Connectors:
4-pin terminal block for RS485 (A/B) and power (+/-)
Cable Requirements Power:
18–14 AWG (0.13–2.0809 mm ). Qualified for up to 200 m (656 ft) – 18 AWG
Cable Requirements Reader Data:
1 twisted pair with shield, 22–14 AWG ( 0.13–2.0809 mm ), 120 ohm impedance, for A and B Qualified for up to 1000 m (3281 ft) – 22 AWG
Operating Conditions:
-40 °C to 65 °C (-40 °F to 149 °F) Humidity 10–100% RH (condensing)
Storage Conditions:
-40 °C to 65 °C (-40 °F to 149 °F) Humidity 5–95% RH (non-condensing)
Dimensions:
121 x 48 x 27 mm (4.76 x 1.89 x 1.06 in)
Optional Accessories:
AXIS TA4711 Access Card AXIS TA4712 Key Fob
Substance Control:
PVC free RoHS in accordance with EU RoHS Directive 2011/65/ EU and 2015/863, and standard EN IEC 63000:2018 REACH in accordance with (EC) No 1907/2006. For SCIP UUID, see echa.europa.eu
Materials:
Screened for conflict minerals in accordance with OECD guidelines To read more about sustainability at Axis, go to axis.com/about-axis/sustainability
Environmental Responsibility:
axis.com/environmental-responsibility Axis Communications is a signatory of the UN Global Compact, read more at unglobalcompact.org
