APC by Schneider Electric AP8869HDX632 Rack PDU 14.4KW 208V (36) C13 & (12) C19
Overview
The APC by Schneider Electric AP8869HDX632 is a 14.4kW, 208V Rack Power Distribution Unit (PDU) designed for high-density IT environments. It provides granular power monitoring at the PDU and outlet level, enabling better capacity planning and load balancing for critical equipment. This unit is engineered for data centers and enterprise closets where precise power management is essential to prevent overloads and ensure uptime for servers, network switches, and storage arrays. The AP8869HDX632 model offers a zero-U form factor, maximizing rack space utilization.
Compatibility
This PDU is designed for integration into standard 19-inch server racks. It is compatible with APC's EcoStruxure IT Data Center Infrastructure Management (DCIM) software and StruxureWare Data Center Expert platforms for centralized monitoring and control. It is intended for use with 208V single-phase or three-phase power distribution systems commonly found in enterprise data centers. While not tied to specific server brands, it is a foundational component for any rack-based IT deployment requiring robust power distribution and monitoring.
Installation Notes
The AP8869HDX632 features a zero-U, vertical rack-mount design, requiring no horizontal rack space. It connects to a 208V power source via a hardwired input or a specific NEMA L6-70P connector (verify exact input connector based on specific sub-model or region). The unit requires adequate airflow within the rack for heat dissipation. Ensure the power source can support the PDU's maximum load of 14.4kW. Proper grounding is mandatory for safe operation.
What's in the Box
- 1x AP8869HDX632 Rack PDU
- 1x Installation Guide
- 1x Serial Configuration Cable
- 1x Rack Mounting Hardware Kit
