Pelco POE130-XT PoE Extender 802.3af/at

The Pelco POE130-XT is a single-port Power over Ethernet extender designed to extend network and power delivery up to 100 meters beyond your primary PoE switch. Supporting IEEE 802.3af/at standards, this inline extender enables total camera cable runs up to 200 meters over Cat5e or Cat6 cabling—eliminating the need for local power infrastructure at the extender location.

Key Features

• Single-port PoE extender for IEEE 802.3af/at compliance
• Extends PoE reach 100m beyond switch port
• Supports total runs up to 200m using Cat5e/Cat6
• Passes both data and power through single cable segment
• No local power source required at extender
• Daisy-chainable for extended deployments
• NDAA Section 889 compliant
• 1-year manufacturer warranty

Technical Highlights

Install the POE130-XT inline at or near the 100-meter mark between your PoE switch and camera. For installations requiring more than 200 meters total cable run, multiple extenders can be daisy-chained in series—verify cumulative power loss remains within your camera's power specifications. Where fiber infrastructure is available, consider SFP media converters to eliminate distance constraints entirely.

Applications

Ideal for commercial and industrial surveillance deployments where camera placement exceeds standard PoE distance limitations. Engineered for enterprise-grade installations, government-regulated environments, and professional Pelco camera system integration.
