Pelco ESSE1-2X40-SPT-AC 2MP 40x PTZ IP69K Washdown Camera
The Pelco ESSE1-2X40-SPT-AC is a professional PTZ camera engineered for environments where standard cameras fail—food processing plants, pharmaceutical wash stations, marine installations, and offshore platforms. Built from 316L stainless steel and rated IP69K, this unit survives direct 100 bar high-pressure washdowns without compromising surveillance continuity. The AC power input variant is optimized for facilities with permanent AC mains wiring at the mounting location, eliminating the need for dedicated PoE infrastructure at remote high-moisture mounting points.
Key Features
- 40x optical zoom (4.3–129 mm focal length): Transitions from 77° wide horizontal field of view to 2.1° telephoto in a single camera, reducing the number of installations needed to cover mixed-distance monitoring zones—critical in large warehouse or processing facility layouts where wide perimeter coverage and detailed far-end observation are both required.
- 2 MP resolution (1920 × 1080) at 60 fps: 2 MP is the practical minimum for PTZ deployments where zoom framing must remain intelligible; 60 fps capture smooths pan/tilt motion and prevents stuttering during high-speed preset recalls—noticeable quality factor in sites with active ISO compliance inspections.
- H.265 and H.264 compression support: H.265 reduces bitstream size roughly 40–50% compared to H.264 at equivalent visual quality, easing storage demand and network load on facilities recording continuous 24/7 across multiple PTZs. H.264 fallback ensures compatibility with older VMS platforms.
- 360° continuous pan with -90° to +1° tilt and 256 preset positions: Endless pan rotation enables tracking across the full horizon without reset delays; 256 presets allow granular coverage of specific zones (e.g., production lines, dock areas, tank fields) without manual joystick input. Useful for unattended shift monitoring.
- 316L stainless steel housing with IP69K, IP68, IP67, and IP66 ratings: 316L resists saltwater corrosion and caustic cleaning agents far better than powder-coated aluminum; IP69K (the highest ingress rating) handles jet washing and steam cleaning cycles routinely applied in food, beverage, and pharmaceutical environments. Lower ratings (IP67, IP66) still available if washdown intensity is moderate.
- Extreme operating temperature range: -40°C to +60°C (-40°F to +140°F): Cold tolerance is critical for frozen food facilities and outdoor polar/high-altitude deployments; high-end tolerance handles direct sun on rooftops or process-generated heat near ovens or steam lines without thermal shutdown.
- 130 dB wide dynamic range: Handles scenes with bright reflective surfaces (stainless steel equipment, water spray) and dark shadows (warehouse corners, under-table areas) in the same frame—essential for compliance footage that must show detail across light and dark zones simultaneously.
- 0.1 lux minimum illumination: Allows surveillance in dim processing areas and night-shift environments with minimal auxiliary lighting; combined with the wide zoom range, enables detail capture in low-light dock or storage zones.
- Pelco Smart Analytics with washdown-rated detection: On-camera motion, intrusion, and object detection operate reliably even during and immediately after washdown cycles when water mist and steam are present—reduces false alarms triggered by cleaning spray, a common problem with standard analytics in wet environments.
- ONVIF Profile S, T, G, and M compliance: Multi-profile support ensures integration with a broad range of third-party VMS platforms (Milestone, Genetec, etc.) and edge devices without proprietary middleware. Profile M support adds metadata streaming for analytics workflows.
- PoE+ power input (alternative to AC): This AC model prioritizes mains infrastructure; verify your installation has AC 24 VAC/DC at the pole or mounting surface before choosing this variant over the PoE+ version.
Integration & Compatibility
The ESSE1-2X40-SPT-AC integrates natively with Pelco video management platforms and supports ONVIF-based third-party VMS software. For facilities standardizing on Milestone XProtect, Genetec Security Center, or Hanwha Vision's SmartVMS, ONVIF Profile S/T/G/M ensures plug-and-play camera discovery and streaming without custom drivers. The AC power variant suits installations where PoE switches are distant or where AC mains availability is cheaper than running PoE cabling to a rooftop mount.
Frequently Asked Questions
Q: Is the ESSE1-2X40-SPT-AC NDAA Section 889 compliant?
A: Yes. Pelco confirms NDAA Section 889 compliance for this model, appropriate for U.S. federal and state government procurement.
Q: What is the warranty coverage?
A: The ESSE1-2X40-SPT-AC includes 5-year manufacturer warranty covering defects in materials and workmanship.
Q: Can I use this camera with a standard PoE switch instead of AC power?
A: No. The ESSE1-2X40-SPT-AC (SPT-AC variant) is designed for 24 VAC/DC input. If you require PoE+ deployment, specify the ESSE1-2X40-SPT-POE variant instead.
Q: Does the IP69K rating handle high-pressure washdowns?
A: Yes. IP69K is specifically rated for jets up to 100 bar (1450 psi) from any angle, typical of industrial and food-service washdown protocols. The 316L stainless construction adds corrosion resistance to water and cleaning chemicals.
Q: What is the minimum illumination for useful video at full zoom?
A: The ESSE1-2X40-SPT-AC achieves 0.1 lux in color mode at wide angle. At full 40x zoom (2.1° FOV), illumination demand increases; auxiliary IR or lighting is recommended for detail capture in very dim areas beyond 0.1 lux.
Q: Is Milestone XProtect compatibility guaranteed?
A: ONVIF Profile S and T support ensures compatibility with Milestone XProtect Professional and Enterprise. Integration is ONVIF-standard; no proprietary plugin required. Verify your Milestone version supports Profile S/T before deployment.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The ESSE1-2X40-SPT-AC is purpose-built for washdown environments where standard IP67 cameras become liability. The 316L stainless construction combined with IP69K rating and 0.1 lux sensitivity makes this a solid fit for food processing, pharmaceutical cold storage, and marine platforms—three market segments where compliance footage must survive cleaning agents, thermal shock, and salt spray without degradation.
Technical Highlights:
- 40x optical zoom (4.3–129 mm): Eliminates need for multiple cameras covering the same area; a single ESSE1-2X40-SPT-AC can transition from perimeter scan (77° wide) to license-plate detail (2.1° tele) without repositioning—direct cost reduction in camera count and wiring runs.
- H.265 codec with 60 fps @ 2 MP: Storage footprint drops 40–50% versus H.264. On a 24/7 multi-camera system, that gap compounds quickly. At 60 fps, pan/tilt motion stays fluid during audit playback—detail matters when regulators watch recorded footage.
- 130 dB WDR: Stainless steel tanks and equipment create specular reflections. WDR keeps dark corners and bright surfaces both intelligible in a single frame—essential for traceability audits in pharma and food plants.
- IP69K + 316L stainless: IP67 fails here. IP69K handles 100 bar jets; stainless resists both caustic detergent and saltwater. Typical powder-coat cameras corrode or fail seal integrity within 12–18 months in these conditions.
Deployment Considerations:
- AC power requirement: This SPT-AC variant requires 24 VAC/DC at the mount. If your facility lacks AC mains wiring at the pole, the PoE+ variant (ESSE1-2X40-SPT-POE) is the fallback—but verify PoE availability and switch power budget before defaulting to it. AC is often cleaner in wet sites anyway (fewer PoE injector boxes to protect).
- Zoom and low light trade-off: 0.1 lux performance is measured wide angle. At full 40x zoom in the same light, expect 1–2 lux minimum for usable detail. If your site is dark at zoom distance, plan for supplemental LED or IR lighting alongside the camera.
- PoE+ alternative: If AC is unavailable, the PoE+ variant draws within standard 802.3at budget—but verify your switch has power headroom and supports Profile S/T for your chosen VMS.
Deploy the ESSE1-2X40-SPT-AC where washdown is non-negotiable (frozen food lines, pharmaceutical clean rooms, offshore marine decks, caustic processing) and compliance video must survive both the environment and regulatory scrutiny. It's overspecified and costly for temperate indoor warehouses—a standard IP66 bullet or dome saves 30–40% capex there. But in harsh washdown sites, the stainless + IP69K + WDR combination justifies the premium and avoids premature replacement cycles.
Key Specifications:
Color: White
