Panduit OM4 2F 1.6MM PC Lszh LC Dup/sc PK1MOQ10 - FZ2ELLNSNSNM6.5

Panduit FZ2ELLNSNSNM6.5 OM4 LC Duplex to SC Fiber Patch Cable

Overview

The Panduit FZ2ELLNSNSNM6.5 is a pre-terminated OM4 multimode duplex fiber optic patch cable from the Panduit QuickNet™ line, built for structured cabling environments where installation speed and compliance matter. The 1.6mm low-smoke zero-halogen (LSZH) jacketed, 2-fiber construction with LC Duplex to SC terminations targets data centers, telecommunications rooms, entrance facilities, and equipment distribution areas — anywhere you need certified pre-terminated fiber infrastructure deployed without field termination delays. LSZH jacketing means combustion byproducts are substantially reduced, making this the correct choice over PVC-jacketed alternatives in plenum or enclosed spaces where occupant safety standards apply.

Compatibility

Designed for OM4 multimode (50/125µm) infrastructure and compatible with equipment using LC Duplex (equipment side) and SC (patch panel or switch side) interfaces. This LC-to-SC configuration is standard for patching between network switches with LC SFP+ ports and legacy SC-terminated fiber panels or backbone infrastructure. Meets TIA-568.3-D, ISO/IEC 11801, and ANSI/TIA-942-B, so it integrates directly into data center structured cabling systems requiring documented compliance without additional field certification. OM4 bandwidth supports 40G and 100G applications at appropriate distances — confirm link budgets per your active equipment specs before deploying at extended reach. The QuickNet™ pre-terminated format is designed to pair with Panduit fiber patch panels and QuickNet cassette systems, though the LC/SC interface is industry-standard and not proprietary-locked.

Installation Notes

LSZH jacketing is required in many European installations and increasingly specified in US environments under NFPA 130 (transit) and IEC 60332 fire standards — verify your local code requirements before substituting a PVC-jacketed alternative. The 1.6mm jacket diameter is slimmer than standard 2mm or 3mm patch cords, which reduces bend radius stress in high-density trays and improves airflow in cable management systems — a practical advantage in fully loaded patch fields. Factory termination eliminates on-site insertion loss variability; inspect ferrule end-faces per IEC 61300-3-35 before installation in high-density links.
