Panduit FRZTP77X001F030 OM4 12-Fiber Plenum PanMPO Trunk Cable

The Panduit FRZTP77X001F030 is a factory-terminated OM4 12-fiber trunk cable designed for high-density datacenter and enterprise backbone installations. Featuring PanMPO-12 Female connectors on both ends with Method A (straight-through) polarity, this 30-foot plenum-rated assembly supports 40GBASE-SR4 and 100GBASE-SR4 applications up to 150 meters. Optimized insertion loss and aqua jacket color coding ensure reliable performance and instant visual identification in structured cabling environments where speed, accuracy, and code compliance are non-negotiable.

Key Features

OM4 50/125 µm multimode fiber rated for 40G/100G Ethernet over 150m links

PanMPO-12 Female connectors both ends with Method A polarity for predictable array-to-array patching

Optimized insertion loss grade ensures headroom in loss budgets for high-speed optics

Plenum (OFNP) jacket meets NEC Article 770 for air-handling spaces without conduit

Aqua jacket follows TIA-598-D color standard for instant OM4 identification

Factory-terminated and tested—eliminates field splicing, reduces install time and error risk

This trunk cable addresses the core challenge in modern datacenters: delivering 12 parallel fiber paths in a single, compact, pre-verified assembly. OM4 laser-optimized fiber supports 40 Gb/s and 100 Gb/s QSFP+ and QSFP28 transceivers across backbone and horizontal links, with an effective modal bandwidth of 4700 MHz·km at 850 nm. The PanMPO connector system uses a multi-fiber push-on interface with a choice of polarity methods—this Method A (straight-through) variant pairs with standard duplex breakout modules and cassettes for array-to-duplex architectures in spine-leaf topologies. Optimized insertion loss grading means each connector is tested to a tighter tolerance than the 0.75 dB TIA-568 maximum, preserving margin for transceiver sensitivity and patch-cord concatenation in multi-tier deployments.

In the field, pre-terminated trunks like the FRZTP77X001F030 cut deployment time by 70% compared to pull-and-splice methods, reduce labor cost, and eliminate the risk of contamination or misalignment that causes intermittent link errors. The 30-foot length suits intra-rack and cross-aisle runs in hot-aisle/cold-aisle layouts, main distribution area (MDA) to horizontal distribution area (HDA) links, and equipment-to-patch-panel connections where structured pathways keep bend radius within the 10× fiber diameter spec. Plenum rating allows installation in return-air plenums and above drop ceilings without additional raceway, simplifying pathway design and passing AHJ inspection on the first visit. Aqua jacket color is the universal OM4 marker—crews can trace, test, and troubleshoot without pulling labels or consulting as-builts under time pressure.

The FRZTP77X001F030 meets TIA-568-C.3, ISO/IEC 11801, and TIA-604-5 (FOCIS-5) standards for multimode fiber interconnects, ensuring interoperability with transceivers, patch panels, and cassettes from any standards-compliant vendor. Factory termination includes end-face geometry inspection and insertion-loss certification, backed by Panduit's quality process—every assembly ships with test data. For integrators managing hyperscale builds, colocation fit-outs, or enterprise edge-to-core upgrades, this trunk cable is the reliable, code-compliant, field-proven solution that keeps projects on schedule and networks performing at design capacity from day one.
