Panduit FRXTP77Y001F082 Opti-Core 12-Fiber OM3 Plenum Trunk Cable

The Panduit FRXTP77Y001F082 is a factory-terminated 12-fiber OM3 multimode trunk cable designed to eliminate field termination in plenum-rated spaces. At 82 feet, this Opti-Core trunk bridges equipment racks, distribution frames, or cross-connects in data centers and telecom rooms where speed, reliability, and code compliance are non-negotiable. Both ends are pre-loaded with duplex LC connectors in Polarity B configuration, ensuring proper transmit/receive mapping across parallel optics without field re-pinning. Every fiber is factory-tested and shipped with insertion-loss certification, removing the variability and labor overhead of on-site fusion splicing or epoxy-polish termination.

Key Features

• 12-fiber OM3 (50/125µm) laser-optimized multimode construction supports 10GBASE-SR to 300m and 40/100GBASE-SR4 to 100m per TIA-568.3-D
• Plenum-rated OFNP jacket meets NEC Article 770 for installation in air-handling spaces without conduit
• Factory-terminated duplex LC connectors on both ends with Polarity B pinout (A-to-B strand mapping for 40G/100G QSFP transceivers)
• 82-foot (25-meter) length spans typical row-to-EOR or floor-to-MDF distances in raised-floor data centers
• Opti-Core sub-brand indicates Panduit's premium trunk line with lifetime performance warranty and insertion-loss test reports included
• Aqua jacket color-codes OM3 grade per TIA-598-D, preventing accidental deployment on OM4/OM5 links or legacy OM1/OM2 infrastructure
• Push-pull boot design on all connectors for single-hand insertion in high-density panels
• Sequential fiber numbering and cable tagging for rapid troubleshooting and MAC operations

OM3 fiber delivers 2000 MHz·km modal bandwidth at 850nm, sufficient for 10 Gigabit Ethernet links up to 300 meters and 40/100 Gigabit SR4 parallel optics to 100 meters. This makes the FRXTP77Y001F082 the right choice for spine-leaf topologies, SAN fabrics, or any 10G/40G aggregation layer that will remain in service through multiple server refresh cycles. The 50-micron core is laser-optimized for VCSEL transceivers, yielding lower bit-error rates and longer reach than older OM1/OM2 grades, while the 12-fiber count provides six duplex circuits—enough for a full 40GBASE-SR4 link (which consumes eight fibers) plus four spare strands, or six independent 10G links with room for future breakout. Polarity B configuration means Fiber 1 on End A maps to Fiber 12 on End B, Fiber 2 to Fiber 11, and so on; this flip-pattern is required for QSFP-to-QSFP 40G links using MPO-to-LC breakout modules, and it's the TIA-568 Method B standard that most switch vendors assume in their cabling guides. Field technicians can verify polarity with a visual fault locator and the included test report, but re-termination is unnecessary—Panduit's automated polishing process holds insertion loss below 0.35dB typical, well under the 0.75dB TIA channel budget.

The plenum OFNP jacket is the defining feature for installations in drop ceilings, raised floors, or HVAC plenums where local fire codes prohibit PVC-jacketed cables. Plenum-rated compounds are formulated to self-extinguish and produce minimal smoke under fire conditions, meeting NFPA 262 flame-propagation and UL 910 Steiner Tunnel tests. This compliance eliminates the need for metallic conduit in air-handling spaces, which translates to faster pulls, lower material cost, and simpler pathway fills. For integrators managing TIA-942 Rated-3 or Rated-4 data center builds, plenum trunks are often the only cable type allowed between the main distribution area and horizontal distribution zones; using a riser-rated or general-purpose cable in these spaces will trigger AHJ rejection and costly rework. The 82-foot length is field-measured to cover the typical distance from a center-of-row patch panel to an end-of-row aggregation switch (roughly 20-25 meters), accounting for vertical rise from under-floor to overhead ladder rack, horizontal run along the cable tray, and service loop at both termination points. Pre-terminated trunks remove the need for fusion splicers, cleaning stations, and factory-certified fiber techs on-site; a two-person team can complete a 12-strand link in under ten minutes, compared to two hours for field termination of the same fiber count, and there's no consumable cost for connectors, epoxy, or polish film.

This trunk is built to TIA-568.3-D (commercial premises fiber standard), ISO/IEC 11801 (international structured cabling), and ANSI/TIA-942-B (data center infrastructure). Compliance with these standards ensures interoperability with any Ethernet switch, SAN director, or fiber channel HBA that adheres to published link-loss budgets, and it's the documentation you'll need to pass BICSI RCDD review or close out commissioning checklists for LEED- or Uptime Institute-certified facilities. Panduit includes a serialized test report with measured insertion loss and return loss for every fiber in the trunk; these numbers go directly into your as-built documentation and provide a baseline for future OTDR troubleshooting if a link degrades. For integration firms managing multi-building campuses or phased data-hall expansions, the Opti-Core platform offers matching trunk lengths from 15 feet to 300 feet in the same OM3/OFNP/Polarity-B configuration, so you can standardize on a single SKU family and maintain consistent sparing and training across all sites. The FRXTP77Y001F082 ships with manufacturer warranty and is RoHS-compliant for disposal or equipment export to EU/APAC regions.
