Panduit FRXTP77Y001F031 OM3 12-Fiber Plenum Trunk Cable

The Panduit FRXTP77Y001F031 is a factory-terminated 12-fiber OM3 multimode trunk cable designed for high-speed data center and enterprise network deployments. This 31-foot plenum-rated assembly eliminates field termination labor and provides reliable 10GBASE-SR connectivity between distribution frames, zone enclosures, and active equipment. Built to TIA-568.3-D and ISO/IEC 11801 standards, the Opti-Core trunk delivers insertion loss consistency and polarity management out of the box, reducing deployment time from hours to minutes in mission-critical environments.

Key Features

• OM3 50/125µm multimode fiber supports 10 Gigabit Ethernet up to 300 meters and 40/100GbE up to 100 meters, future-proofing horizontal and backbone links
• Factory-terminated connectors eliminate fusion splicing, field polishing, and insertion-loss variability—ship-and-install ready
• OFNP plenum rating meets NEC Article 770 for air-handling spaces, supporting code-compliant installations in drop ceilings and raised floors without conduit
• 12-fiber count provides six duplex channels for link redundancy, multi-switch uplinks, or phased equipment migrations without re-cabling
• 31-foot length suits typical rack-to-rack or floor-to-ceiling distribution spans in compact telecom rooms and colocation suites
• Opti-Core construction includes aramid yarn strength members and low-smoke jacket for mechanical protection and fire safety
• TIA-568.3-D and ANSI/TIA-942-B compliance ensures interoperability with enterprise structured cabling and data center tier-rated designs

Pre-terminated trunk cables address the dual challenges of labor cost and performance variance in fiber deployments. Field termination of 12 fibers requires fusion splicers, cleaning protocols, and OTDR verification—introducing both time overhead and insertion-loss risk from environmental contamination or technician inconsistency. The FRXTP77Y001F031 ships with factory-polished connectors tested to industry specs, delivering predictable link budgets and eliminating the need for on-site termination equipment. Installers pull the cable, plug it in, and verify continuity—cutting deployment windows from half-day events to sub-hour tasks and removing the need for fiber-certified field staff on routine installations.

The OM3 fiber specification positions this trunk for current 10G SFP+ links and future 40G/100G QSFP migrations without re-cabling. Enterprises standardizing on 10GBASE-SR for storage-network convergence or access-layer uplinks gain 300-meter reach per duplex pair, covering intra-building distribution and most campus backbone spans. Data centers deploying 40G spine-leaf fabrics or 100G core switches achieve 100-meter OM3 reach with QSFP28 SR4 optics, supporting single-tier leaf topologies and eliminating the need for OS2 single-mode fiber in compact facilities. The 12-fiber count provides capacity for six independent 10G links, three 40G links, or one 100G link with spares—offering flexibility for phased equipment upgrades, redundant-path designs, or future bandwidth expansion without trunk replacement.

This trunk is built for environments where installation speed, code compliance, and link reliability outweigh the material cost of pre-terminated assemblies. Colocation tenants facing strict change-window constraints eliminate splicing labor and post-install testing delays. Telecom rooms serving multi-floor enterprises use the plenum jacket to traverse air-return plenums between risers and IDF racks without costly conduit or fire-stop retrofits. Integrators managing multiple deployment sites reduce truck-roll variability by standardizing on known-good factory assemblies rather than depending on field technician skill and calibration state of portable fusion equipment.
